NPM- TT2 EJM1EE-MB-04 O-03 Ｓｅｔｔｉｎｇ change 4-2-9 -17 6 ■ When a component is picked up to t he nozzle manually 7 To + ■ When a component is picked up to the nozzle automatically 14 To + 7 Prepare for component installatio…
NPM-TT2 EJM1EE-MB-04O-03
Teaching by specifying component position 1
Produc-
tion data
teaching
Placement coordinates
teach 9
Operating procedure
4-2-9
4-2-9-16
1
Perform steps from to in
[Teaching with component
(measuring method: 1 point)]
1
7
2
2
4
Confirm the message
5
with
Choose
5
●Perform on both and .
4
■When you do not want to transition to
the component position selection
screen
3
3
+
NPM-TT2 EJM1EE-MB-04O-03
Ｓｅｔｔｉｎｇ
change
4-2-9-17
6
■When a component is picked
up to the nozzle manually
7
To
+
■When a component is picked
up to the nozzle automatically
14
To
+
7
Prepare for component
installation
8
9
10
11
12
Open the safety cover
Servo switch OFF
Install components
Close the safety cover
13
Confirm the message
13
6
Servo switch ON
NPM-TT2 EJM1EE-MB-04O-03
Teaching by specifying component position 2
Produc-
tion data
teaching
Placement coordinates
teach 10
Operating procedure
4-2-9
4-2-9-18
+
14
13
15
15
17
■When an image is recognizable
18
To
■In the case of recognition
error, or unclear image
17
To
17
16
Confirm the recognition result
16
■For recognition error, the button
is grayed out
and becomes disabled
■Adjustment is necessary
since pins for insertion
components are not easy to
recognize
(→P.4-2-1 ‘How to adjust the lamp value’)
