NPM- TT2 EJM1EE-MB -04O-03 4-2-10 -6 Ｓｅｔｔｉｎｇ change
NPM-TT2 EJM1EE-MB-04O-03
17
Confirm the message
15
To reconfirm the test result
(The test result of is displayed)
12
11
Produc-
tion data
teaching
Bad mark recognition
teach 3
14
After confirming the
recognition result
16
●You may transition to the other
screen.
16
4-2-10-5
17
+
Operating procedure
4-2-10
14
TH : Threshold
Level : Luminosity
Rate : Pixel rate
NPM-TT2 EJM1EE-MB-04O-03
4-2-10-6
Ｓｅｔｔｉｎｇ
change
NPM-TT2 EJM1EE-MB-04O-03
Produc-
tion data
teaching
Tray pickup position
teach 1
4-2-11-1
Operating procedure
4-2-11
Selecting the address of the tray to teach
Selecting a teaching mode
Teaching the pickup start position
Teaching the pickup end position
Completion of teaching
Teaching Flow
The tray data teaching fine-adjusts the pickup position on the basis of the tray data (tray
dimensions, pickup start position, pickup end position, chip count, etc.).
The tray data teaching teaches the positions of the components to be picked up first and
last with the help of images captured by the head camera. The pickup positions of other
components are automatically calculated based on the number of components arranged in
a matrix.
