NPM-TT2 EJM1EE-MB-05O-05
Setting information 3
System
administration
5-1-1-4
● Default ：OFF
■Whole
No. Item name Function when [ON] is selected
31
Pre-pickup Inspection
(Option)
Check the supplied components before picking them up.
32
Save whole image of the
pre-pickup inspection
(Option)
Saves the entire image of the specified component during the pre-pickup
inspection.
33
No recog and PCB pass
when PCB recog Error.
Shows the [No recog] and [PCB pass] buttons on the PCB recognition error
screen.
34
Pickup miss count in the
start up tape status
Includes the pickup errors occurred during tape feed start in the Pickup
count and Pickup error count in the Production report.
35
Recognition history LNB
transfer during error stop
Transfers the recognition history to the LNB when the machine has stopped
due to an error.
36
Split and output recipe
per lot
Divides the production data to be output lot by lot. Set this option to ON
when the “Output production data divided lot by lot” is ON in the DGS
production data setting.
37
In production Product
manage information
display
Production management information can be referred to during automatic
operation (without interrupting the machine).
However, if it is displayed during automatic operation, an error screen such
as the PCB recognition error screen cannot be displayed. The error screen
is displayed at the timing when you go back to the screen in production
from the production management information screen.
38
PCB ID confirm during
auto running resume
If you exit automatic operation halfway through the mounting process that
uses production data based on PCB ID scanning, the machine recognizes
the PCB barcode using its head camera and confirms PCB ID before
resuming automatic operation. The machine comes to an error stop if the
PCB located at the mounting position at the time of exit from automatic
operation is not identical in PCB ID (PCB info) to the one recognized, as
mentioned above, using the head camera. In such case, putting the former
back in the mounting position allows the machine to resume automatic
operation.
39
Parts Empty Warning
Auto Screen Transition
It is available only when [Empty Parts Auto Screen Transition] or [Empty
Parts Auto Screen Transition(with stock)] is on. If this parameter is ON it
will also transfer to production remaining monitor screen(machine)
automatically when parts empty warning
40
NG part Eject before
mounting (MntPosMov)
This function is only aimed at 16 nozzle head. After ending the parts
recognition if there are parts judged as pickup error or recognition error or
lead float after moving the mount position without executing the mount
action eject the parts and execute the mount action again when it is ON and
eject the parts after the mount action when it is OFF. (The error parts still
pass on the PCB even if it is ON.)
41
Production data DL by
Form Reading
According to reading the barcode from the wired scanner of first equipment
select the next production program and download to equipment.
NPM-TT2 EJM1EE-MB-05O-05
5-1-1-5
Setting information 4
Unit
setting
Option setting 3
Operating procedure
5-1-1
No. Item name Function when [ON] is selected
1
Nozzle 2D code
recog
Detects wrong nozzle setting and checks for proper orientation of nozzle on
the nozzle changer by recognizing the 2D code on the nozzle at the start of
automatic operation.
2
Can't use the Nzl
without 2D Code
Causes the machine to stop if nozzles without 2D code are mixed up.
3
2D code recognition
only when nozzle
exchange
Causes the head camera to skip 2D code recognition of all nozzles set in the
nozzle changer when restarting the machine that has been stopped during
production.
4
Temperature warning
check
Compares the current temperature of adhesive with the preset value on the
temperature control unit.
5
Inside changer auto
arrange
Rearranges the nozzles on the nozzle changer according to the data after
recognizing the nozzle 2D code.
6
Bad mark recognition
judge value is
variable
Uses the criterion value in the bad mark information to judge the bad mark
recognition for production boards.
7
Bad nozzle auto
change
If a certain nozzle is determined to be bad due to “Bad nozzle error rate”, this
option replaces the nozzle concerned with a normal one automatically. (12-
/16-nozzle heads)
8
Continue to product
when stuff detect
Allows production to be continued even after an error has occurred due to
detection of stuffed nozzle or filter.
9
Big nozzle manual
change (front side)
Enables the nozzles to be set manually without replacing them automatically.
10
Big nozzle manual
change (rear side)
Enables the nozzles to be set manually without replacing them automatically.
No. Item name Function when [ON] is selected
1 Bad XY axis(front) Disables the front XY unit.
2 Bad XY axis(rear) Disables the front XY unit.
3
Time-lapse change
calibration during
producing of one
piece
Performs time-lapse change calibration during production of one PCB.
● Default ：OFF
■ XY-axis
● Default ：OFF
■ Head
NPM-TT2 EJM1EE-MB-05O-05
5-1-1-6
Setting information 5
System
administration
No. Item name Function when [ON] is selected
1 Force PCB Eject
Ejects PCB forcibly even if there is no PCB request signal from the
downstream machine.
2
Pre process other
company M/C joint
Makes the timing of PCB request signal OFF from the downstream machine
earlier.
3
Pre process other
company M/C joint2
Hastens the timing of PCB request signal OFF from the downstream machine.
4
All pattern bad board
pass
When all patterns are judged to be bad by bad mark recognition, this option
unloads the board to the downstream side without mounting parts on it.
5 F Proc. Eject Wait
When a third-party machine or conveyor is connected on the upstream side,
and “B. A. (Board Available) signal from it is received, PCB request signal is
sent to the upstream machine or conveyor, and a PCB is loaded.
6
Production item name
check
When this option is ON, the NPM machine checks the product name before a
PCB is loaded from the upstream machine. If the production data names do
not agree, the NPM comes to a single error stop.
7
Width adjustment
fixed
Disables width adjustment at any operation screen even during automatic
operation.
8
PCB connection
detect
Determines an error if two PCBs connected with onto each other are loaded.
9
Conveyor width check
before production
Checks that the conveyor width matches the setting in the production data
before starting production.
10
Positioning action
when overrun
Allows positioning to be performed again if a loaded PCB has overrun.
11
PCB Y clamp
(option)
Keeps the Y clamp engaged also during mounting.
12
Multiple lot prevent
carrying (option)
Controls the board transfer during dual lane production so that the
subsequent lot will not overtake the lot ahead.
● Default ：OFF
■ Conveyor
No. Item name Function when [ON] is selected
11
Mount blow check
When checks are made for any component that has not been mounted but
carried back by the nozzle, the mount blow is also checked for any problem.
12
Bad nozzle set during
nozzle stuff
In the event of detection of a stuffed nozzle during production preparation,
the nozzle is automatically set as bad nozzle and production operation is
continued.
● Default ：OFF
■ Head
