NPM-TT2 EJM1EE-MB-05O-05
Unit
setting
Action parameter
setting 5
5-1-2-9
Setting information 8
Operating procedure
5-1-2
■Feeder (3/6)
Type Item Description Initial
value
Setting
range
Determine
Tape cutting length (F)
[mm]
Setting value used to cut tape during
automatic operation. Tape is cut when the
longest empty tape on the front table
exceeds this value.
100
10.0 to
2000.0
Tap cutting length (R)
[mm]
Setting value used to cut tape during
automatic operation. Tape is cut when the
longest tape on the rear table exceeds this
value.
100
10.0 to
2000.0
Feeder mainte qty
(8 mm) [ten thousand]
When the maintenance count has reached
this value with feeder maintenance warning
ON, operation cannot be continued.
100 1 to 500
Feeder mainte qty
(12/16 mm) [ten
thousand]
100 1 to 500
Feeder mainte qty
(24/32mm)
[ten thousand]
100 1 to 500
Feeder mainte qty
(44/56mm)
[ten thousand]
100 1 to 500
Feeder mainte qty
(72mm)
[ten thousand]
100 1 to 500
Feeder mainte qty
(88/104/120mm) [ten
thousand]
100 1 to 500
NPM-TT2 EJM1EE-MB-05O-05
Setting information 9
System
administration
5-1-2-10
■Feeder (4/6)
Type Item Description Initial
value
Setting
range
Determine
Feeder mainte
warning rate[%]
The number of times a feeder has been
maintained exceeds the quantity obtained by
“Feeder mainte qty x Setting value”, a feeder
maintenance warning is displayed.
●If 100% is set, only warning is displayed.
100 0 to 100
Pickup position
reteaching
deviation [%]
When the joint part of splicing is detected
and fed at once, and pickup position
automatic teaching is carried out, if the chip
size of MAX L and MAX W exceeds the
value (%) automatic teaching retry is carried
out as recognition result out of area error.
This is used only if the joint part of splicing is
detected and fed at once.
●Iｆ 0 is set, if the chip size of MAX L and
MAX W exceeds ±1mm, it results in error
and no retry is carried out as usual.
0 0 to 100
Pickup position re-
teach count
This sets the maximum number of times
recognition is reattempted for a pickup
position recognition error.
00 to20
Splicing no-check stop
length [mm]
This is the stop length from the joint
detection position in splicing no-check.
●When 0 is set, the joint detection position
becomes the immediate stop position.
●When values other than 0 are set, it
becomes in the warning state and stops at
the length of the set value.
●This function is valid for the feeder
firmware version of 530 or later.
0 0 to 100
Parts empty judge
remains[%]
When the part empty pickup reaches to the
error count, if the number of remaining parts
is not below this set value, the machine
does not judge as parts empty. In this case,
pickup error is also counted.
0
0.000 to
99.999
Splicing judge remains
[%]
Even though splicing is detected, if the
remaining amount is not below this set value,
the machine does not judge as splicing.
●With 0 set, if splicing is detected, the
machine judges as splicing without any
condition.
0
0.000 to
99.999
NPM-TT2 EJM1EE-MB-05O-05
Unit
setting
Action parameter
setting 6
5-1-2-11
Setting information 10
Operating procedure
5-1-2
■Feeder (5/5)
Type Item Description Initial
value
Setting
range
Determine
Auto Tape Moving
Remain [%]
Even if parts are fed as many times as the
set value after the remaining number of the
parts being used reaching 0, information on
all parts in the splicing unit will be reflected
in the unit where parts are used if any splice
joint is not detected.
●Enabled when feeder verification or
remaining warning is set to ON.
00 to 15
The remains when the
joint not pass is
selected[%]
When the machine stops after the number of
remaining parts reaches “1”, selecting “the
join not pass” sets the “default value x the
setting value” as the remaining number of
parts.
0 0.0 to 100.0
Unfixed cnt. before
Splicing [piece]
Ignores as many errors as the number of the
parts set at the trailing edge of the reel on
the machine side after completion of splicing.
Because the improper taping of splicing tape
is likely to cause pickup errors, this is used to
ignore such errors as an unstable zone.
00 to 3
Feed length
(8mm) [mm]
When production starts, the number of chips
obtained from specified length / pitch is
compared with the number of chips currently
set on workpiece exhaust, and the larger one
is applied for the number of workpiece
exhaust chips.
●Applicable feeder: 8mm or less (Paper,
embossed).
0 0.0 to 120.0
Pickup position gap
retry count
When a pickup position gap has occurred, a
retry can be attempted in combination with
pickup position teaching as many times as
specified by this setting value.
00to5
In pickup position
teach Tape feed limit
judge value[Piece]
When the tape feed in pickup position
teaching has exceeded the limit length
(Judge value x Feed pitch), tape feed will be
limited.
00 to20
Splicing Position
Unfixed Length[mm]
When this value is other than 0 and “joint
detection” in the mount condition data is “1.
Excluded from errors”, unfixed count
processing is carried out for the length set
here. Fractions are rounded up. (When
excluded from errors, the “Whole Feed
Count” is handled as “Splicing Position
Unfixed Count”.
0.0
0.0 to
100.0
