NPM-TT2 EJM1EE-MB-05O-05
Setting information 9
System
administration
5-1-2-10
■Feeder (4/6)
Type Item Description Initial
value
Setting
range
Determine
Feeder mainte
warning rate[%]
The number of times a feeder has been
maintained exceeds the quantity obtained by
“Feeder mainte qty x Setting value”, a feeder
maintenance warning is displayed.
●If 100% is set, only warning is displayed.
100 0 to 100
Pickup position
reteaching
deviation [%]
When the joint part of splicing is detected
and fed at once, and pickup position
automatic teaching is carried out, if the chip
size of MAX L and MAX W exceeds the
value (%) automatic teaching retry is carried
out as recognition result out of area error.
This is used only if the joint part of splicing is
detected and fed at once.
●Iｆ 0 is set, if the chip size of MAX L and
MAX W exceeds ±1mm, it results in error
and no retry is carried out as usual.
0 0 to 100
Pickup position re-
teach count
This sets the maximum number of times
recognition is reattempted for a pickup
position recognition error.
00 to20
Splicing no-check stop
length [mm]
This is the stop length from the joint
detection position in splicing no-check.
●When 0 is set, the joint detection position
becomes the immediate stop position.
●When values other than 0 are set, it
becomes in the warning state and stops at
the length of the set value.
●This function is valid for the feeder
firmware version of 530 or later.
0 0 to 100
Parts empty judge
remains[%]
When the part empty pickup reaches to the
error count, if the number of remaining parts
is not below this set value, the machine
does not judge as parts empty. In this case,
pickup error is also counted.
0
0.000 to
99.999
Splicing judge remains
[%]
Even though splicing is detected, if the
remaining amount is not below this set value,
the machine does not judge as splicing.
●With 0 set, if splicing is detected, the
machine judges as splicing without any
condition.
0
0.000 to
99.999
NPM-TT2 EJM1EE-MB-05O-05
Unit
setting
Action parameter
setting 6
5-1-2-11
Setting information 10
Operating procedure
5-1-2
■Feeder (5/5)
Type Item Description Initial
value
Setting
range
Determine
Auto Tape Moving
Remain [%]
Even if parts are fed as many times as the
set value after the remaining number of the
parts being used reaching 0, information on
all parts in the splicing unit will be reflected
in the unit where parts are used if any splice
joint is not detected.
●Enabled when feeder verification or
remaining warning is set to ON.
00 to 15
The remains when the
joint not pass is
selected[%]
When the machine stops after the number of
remaining parts reaches “1”, selecting “the
join not pass” sets the “default value x the
setting value” as the remaining number of
parts.
0 0.0 to 100.0
Unfixed cnt. before
Splicing [piece]
Ignores as many errors as the number of the
parts set at the trailing edge of the reel on
the machine side after completion of splicing.
Because the improper taping of splicing tape
is likely to cause pickup errors, this is used to
ignore such errors as an unstable zone.
00 to 3
Feed length
(8mm) [mm]
When production starts, the number of chips
obtained from specified length / pitch is
compared with the number of chips currently
set on workpiece exhaust, and the larger one
is applied for the number of workpiece
exhaust chips.
●Applicable feeder: 8mm or less (Paper,
embossed).
0 0.0 to 120.0
Pickup position gap
retry count
When a pickup position gap has occurred, a
retry can be attempted in combination with
pickup position teaching as many times as
specified by this setting value.
00to5
In pickup position
teach Tape feed limit
judge value[Piece]
When the tape feed in pickup position
teaching has exceeded the limit length
(Judge value x Feed pitch), tape feed will be
limited.
00 to20
Splicing Position
Unfixed Length[mm]
When this value is other than 0 and “joint
detection” in the mount condition data is “1.
Excluded from errors”, unfixed count
processing is carried out for the length set
here. Fractions are rounded up. (When
excluded from errors, the “Whole Feed
Count” is handled as “Splicing Position
Unfixed Count”.
0.0
0.0 to
100.0
NPM-TT2 EJM1EE-MB-05O-05
5-1-2-12
System
administration
Setting information 11
■Feeder (6/6)
Type Item Description Initial
value
Setting
range
Determine
Whole Feed
Length[mm]
When “Action when joint detected” is “0:
Whole Feed (default)”, whole feed is
performed for the length set here. Fractions
are rounded up. “Whole Feed Count” in the
mount condition data prevails over this
setting.
0.0 0.0 to 100.0
Pickup again count
during pickup error
Set the number of times pickup is
reattempted for a pickup error.
11 to3
Unfixed length before
splicing[mm]
Pickup/recognition errors are not counted for
the length set here from the splicing position
on the old reel side.
00to40
Unfixed Length After
Whole Feed[mm]
Pickup/recognition errors are not counted for
the length set here after a whole feed.
00 to40
Feeder defective rate
measure count[cnt]
This is used when Feeder defective rate
warning (specified count) is ON.
Feeder defective rate is calculated when the
measurement count reaches the value set
here.
100
100 to
10000
Terminal detect action
execute judge[%]
This is used to determine whether or not to
perform end detection for the parts fed by
auto loading feeder when “Pickup error stop”
is set at “1” in the mount condition data.
When a pickup error has occurred, end
detection is performed if the following
condition is met: Number of remaining parts
< Initial part quantity x End detection judge
remain[%]. If the end of tape is not detected,
the machine will stop due to a pickup error.
(End detection is not performed when this is
set at 0.)
0.50
0.00 to
10.00
■Transfer (1/2)
Type Item Description Initial
value
Setting
range
Mechanic
Transcription unit film
formation speed
[mm/s]
The maximum speed for forming film. 75 0 to 500
Transcription unit
taking out speed
[mm/s]
The maximum speed for scraping and
retracting.
150 0 to 500
