NPM- TT2 EJM1E E-MB-05O-05 Unit setting Action par ameter setting 7 5-1-2 -13 Setting information 12 Operating procedure 5-1-2 ■ Line camera Type Item Description Initial value Setting range Determine Recog. OK rate [%] …

100%1 / 512
NPM-TT2 EJM1EE-MB-05O-05
5-1-2-12
System
administration
Setting information 11
■Feeder (6/6)
Type Item Description Initial
value
Setting
range
Determine
Whole Feed
Length[mm]
When “Action when joint detected” is “0:
Whole Feed (default)”, whole feed is
performed for the length set here. Fractions
are rounded up. “Whole Feed Count” in the
mount condition data prevails over this
setting.
0.0 0.0 to 100.0
Pickup again count
during pickup error
Set the number of times pickup is
reattempted for a pickup error.
11 to3
Unfixed length before
splicing[mm]
Pickup/recognition errors are not counted for
the length set here from the splicing position
on the old reel side.
00to40
Unfixed Length After
Whole Feed[mm]
Pickup/recognition errors are not counted for
the length set here after a whole feed.
00 to40
Feeder defective rate
measure count[cnt]
This is used when Feeder defective rate
warning (specified count) is ON.
Feeder defective rate is calculated when the
measurement count reaches the value set
here.
100
100 to
10000
Terminal detect action
execute judge[%]
This is used to determine whether or not to
perform end detection for the parts fed by
auto loading feeder when “Pickup error stop”
is set at “1” in the mount condition data.
When a pickup error has occurred, end
detection is performed if the following
condition is met: Number of remaining parts
< Initial part quantity x End detection judge
remain[%]. If the end of tape is not detected,
the machine will stop due to a pickup error.
(End detection is not performed when this is
set at 0.)
0.50
0.00 to
10.00
■Transfer (1/2)
Type Item Description Initial
value
Setting
range
Mechanic
Transcription unit film
formation speed
[mm/s]
The maximum speed for forming film. 75 0 to 500
Transcription unit
taking out speed
[mm/s]
The maximum speed for scraping and
retracting.
150 0 to 500
NPM-TT2 EJM1EE-MB-05O-05
Unit
setting
Action parameter
setting 7
5-1-2-13
Setting information 12
Operating procedure
5-1-2
■Line camera
Type Item Description Initial
value
Setting
range
Determine
Recog. OK rate [%]
This is a criterion used to judge recognition
results good or bad.
If “ANS” of recognition results falls short of it,
a recognition error occurs.
85 0 to 100
Bad mark judge rate
[%]
This is the threshold for bad mark
recognition block matching.
The block is judged to be OK if the result of
matching is equal to or greater than the
value set here.
85 0 to 100
Type Item Description Initial
value
Setting
range
Mechanic
Tray pickup place gap
[mm]
This gap is added in pickup from trays. 0.5 -2.0 to 2.0
■Tray
■ Transfer (2/2)
Type Item Description Initial
value
Setting
range
Timer
Time Keep thick film
time [s]
Coating thickness formation holding time
for the transcription unit.
30 0 to 600
Stamp material
Spill Detect Invalid
Time (F) [s]
After transcription materials at the front side
are automatically supplied, spill detection is
disabled during the set time period.
●It assumes the time between the start of
material dripping off and until dripping off
stops.
0.5 0.0 to 5.0
Stamp material
SpillDetect Invalid
Time (R) [s]
After transcription materials at the rear side
are automatically supplied, spill detection is
disabled during the set time period.
●It assumes the time between the start of
material dripping off and until dripping off
stops.
0.5 0 .0 to 5.0
NPM-TT2 EJM1EE-MB-05O-05
5-1-2-14
System
administration
Setting information 13
■Height sensor
Type Item Description Initial
value
Setting
range
Determine
PCB warpage grade
tolerance [%]
When PCB warpage is measured, if the
tolerance obtained form the height
measurement value exceeds the set value,
the single stop error occurs.
0.5 0.0 to 10.0
Local height result
tolerance [mm]
When the local height on the several
locations are measured, if the minimum and
maximum values exceed the set value, the
single stop error occurs.
0.5 0.1 to 2.0
