NPM-TT2 EJM1EE-MB-05O-05
Unit
setting
Monitor setting
5-1-5-1
Monitor setting
You can configure the settings related to the monitor.
Operating procedure
5-1-5
A
B
C
2
2
1
screen saver
Enter the time (seconds) to shut off the
backlight.
It does not light off when ‘0’ is set.
Time
Enter the current time.
Language
Choose the display language from
among Japanese, English and Chinese.
Fourth language is optional.
■When changing the waiting time to
shut off the screen saver
■When you do not choose the time
Change the numerical number
on the screen
●Touching the screen displays the
input window.
●If the machine is connected to LNB,
the time is adjusted to LNB side,
therefore, you cannot set the time on
the screen.
A B
C5
1
3
Choose the wait time
((The time is registered)
NPM-TT2 EJM1EE-MB-05O-05
5-1-5-2
6
3
4
5
4
4
3
6
Confirm the message
(Time starts)
■When you do not set time
■To change the language
■To enable
■To disable
Enter the
numerical value,
■When you do not enter
●Repeat the steps and
and enter year/month/date/time.
Change the numerical number
on the screen
●Touching the screen displays the
input window.
System
administration
NPM-TT2 EJM1EE-MB-05O-05
Unit
setting
Bad head setting
5-1-6-1
Operating procedure
5-1-6
Choose with
Choose the defect status
of the head using
Only when [Action Bad] is chosen,
confirm the message
You can configure the bad head settings.
Choose nozzle head position
For a placement head
3
4
1
2
(Operation ends)
■When all heads are to [Normal]
4
1 2 3
■When you do not optimize DGS
●”Pickup Bad” appears when the rate of
pickup or recognition errors exceeds
20%.
It is reset after changeover.
●”Action Bad,” which cannot be reset
even after changeover, is not used in
production.
