NPM- TT2 EJM1E E-MB-05O-05 5-1-6 -2 System administration A For a nozzle changer 1 2 1 Confirm the message 3 4 4 ● (Gray): Normal ● (Green): Defective (All nozzles become [Normal]) 3 Confirm a defective nozzle and replac…
NPM-TT2 EJM1EE-MB-05O-05
Unit
setting
Bad head setting
5-1-6-1
Operating procedure
5-1-6
Choose with
Choose the defect status
of the head using
Only when [Action Bad] is chosen,
confirm the message
You can configure the bad head settings.
Choose nozzle head position
For a placement head
3
4
1
2
(Operation ends)
■When all heads are to [Normal]
4
1 2 3
■When you do not optimize DGS
●”Pickup Bad” appears when the rate of
pickup or recognition errors exceeds
20%.
It is reset after changeover.
●”Action Bad,” which cannot be reset
even after changeover, is not used in
production.
NPM-TT2 EJM1EE-MB-05O-05
5-1-6-2
System
administration
A
For a nozzle changer
1
2
1
Confirm the message
3
4
4
● (Gray): Normal
● (Green): Defective
(All nozzles become [Normal])
3
Confirm a defective nozzle and
replace it with the normal nozzle
2A
Choose with
Bad head display
●Displayed when there is any bad
head.
■When you do not want to normalize all
heads
NPM-TT2 EJM1EE-MB-05O-05
Unit
adjust-
ment
All-axes origin return
1
Returns all axes to their origins
+
1
A
A
Operating procedure
5-2-1
(The origin return process starts and the
result is displayed)
Result of origin return
■Axes succeeded in the origin return
■Axes failed in the origin return
●Please consult us.
5-2-1-1
