N7201A652E - 第430页

NPM- TT2 EJM1E E-MB-05O-05 Unit adjust- ment R eplacing the no zzle of the placement head 2 5-2-5 -3 Operating procedure 5-2-5 Installing nozzles Install no zzles in the noz zle changer to the pl acement head. 1 2 3 1 2 …

100%1 / 512
NPM-TT2 EJM1EE-MB-05O-05
5-2-5-2
System
administration
+
+
Select the presence or absence of
a nozzle.
or
Opening or closing of the
nozzle changer shutter
■To open the shutter
■To close the shutter
Set the nozzle positions, displayed in yellow
as discord nozzles, for Discord nzlClear.
●Nozzles, if different from the current ones
that install new production data, are
displayed in yellow.(A nozzle cannot be
attached or removed as it is)
B
A
C
NPM-TT2 EJM1EE-MB-05O-05
Unit
adjust-
ment
Replacing the nozzle of
the placement head 2
5-2-5-3
Operating procedure
5-2-5
Installing nozzles
Install nozzles in the nozzle changer to the placement head.
1
2
3
1
2
3
Choose with
Choose with
Choose a nozzle to install
(The button turns in blue color)
NPM-TT2 EJM1EE-MB-05O-05
5-2-5-4
System
administration
5
Choose the head to
install the nozzle
4
(The button turns in blue color)
+
5
4
