NPM- TT2 EJM1E E-MB-05O-05 5-2-5 -4 System administration 5 Choose the head to install the nozzle 4 (The button turns in blue color) + 5 4
NPM-TT2 EJM1EE-MB-05O-05
Unit
adjust-
ment
Replacing the nozzle of
the placement head 2
5-2-5-3
Operating procedure
5-2-5
Installing nozzles
Install nozzles in the nozzle changer to the placement head.
1
2
3
1
2
3
Choose with
Choose with
Choose a nozzle to install
(The button turns in blue color)
NPM-TT2 EJM1EE-MB-05O-05
5-2-5-4
System
administration
5
Choose the head to
install the nozzle
4
(The button turns in blue color)
+
5
4
NPM-TT2 EJM1EE-MB-05O-05
Unit
adjust-
ment
Replacing the nozzle of
the placement head 3
5-2-5-5
Operating procedure
5-2-5
Installing a nozzle for support pins
1
●In the case of a nozzle for 3-nozzle
head, be careful of the groove
location.
Feeder table side
●A nozzle for 8-nozzle head with 2D code is marked, place it as
an orientation shown in the figure below.
●Using an optional setting, you can avoid wrong installation in
order to detect the nozzle type by 2D code.
Feeder table side
2D code
Nozzle for support pins
ATTENTION
The shape differs from a nozzle for component pickup.
Please install the nozzle for support pins to the nozzle change r for support pins and the nozzle for
component pickup to the one for component pickup.
If you wrongly installed, shaft of the head unit may be damaged.
Describes how to place a nozzle for support pins to a nozzle change for support pins and install it to the
placement head.
Place a nozzle for support pins to the nozzle changer for support pins
100 nozzle
(for 8-nozzle head)
1100 nozzle
(for 3-nozzle head)
2D code
