NPM-TT2 EJM1EE-MB-05O-05
5-2-10-2
System
administration
Button Action Button Action
Displays a concentric scale on the
screen.
Adjusts the brightness.
Displays a quadrangular frame on the
screen.
Displays the recognition system
version
Displays cross hairs on the
recognition screen.
Clears a display image from the
screen.
Checks the captured recognition
image.
Returns to the original screen.
Screen display function
Saving the recognition error history
12
1
2
E
Confirm the message
NPM-TT2 EJM1EE-MB-05O-05
Unit
adjust-
ment
Head camera
information check 2
5-2-10-3
Operating procedure
5-2-10
Saving the error image history
1
2
3
1
Choose the nozzle position
with error
3
2
●Black: Nozzle position on which error
occurred just before
■To confirm the error image
■When you do not neither save
nor confirm
NPM-TT2 EJM1EE-MB-05O-05
5-2-10-4
System
administration
Checking head camera status
A
B
E
F
H
Status and error of each
item
Updates to the latest information.
(The action/image test screen is displayed)
Communication status is displayed.
Test pattern status is displayed.
Returns to the previous screen.
A
CB
D
D
EF
■[Action test] screen
C
Switches the display type.
H
G
Function status is displayed.
G
