NPM- TT2 EJM1E E-MB-05O-05 5-2-10 -6 System administration Checking capture status Status and error of each item ● Updates to the latest information . Switches the display type. A B C A B C

100%1 / 512
NPM-TT2 EJM1EE-MB-05O-05
5-2-10-5
Unit
adjust-
ment
Head camera
information check 3
Operating procedure
5-2-10
Checking LED status
A
B
E
F
G
Status and error of each
item
●Updates to the latest information.
(The action/image test screen is displayed)
Communication status is displayed.
Function status is displayed.
Returns to the previous screen.
D
B
Switches the display type.
E
F G
■[Action test] screen
A
B C
D
NPM-TT2 EJM1EE-MB-05O-05
5-2-10-6
System
administration
Checking capture status
Status and error of each
item
●Updates to the latest information.
Switches the display type.
A
B C
A
B
C
NPM-TT2 EJM1EE-MB-05O-05
5-2-11-1
Unit
adjust-
ment
Multi-recognition camera
information check
Operating procedure
5-2-11
Checking camera status
A
B
Status and error of each item
Updates to the latest information.
C
Switches the display type.
A
B C
