NPM- TT2 EJM1E E-MB-06O-04 Specifi- cation Mac hine specifica tions/ Basic perf or mance 2 6-1-1 -3 Operating procedure 6-1-1 ■ Component recognition ca mera specifications Basic performance Item Multi-recognition camera…
NPM-TT2 EJM1EE-MB-06O-04
Basic performance
6-1-1-2
Item
Specification
8-nozzle head 3-nozzle head
Placement angle 0 to 359 °(It can be set in increments of 0.01°)
Placement range
(→P.6-1-4 ‘Applicable PCB specifications’)
PCB flow direction (→P.6-1-2 ‘PCB flow direction’)
Placement tact time
*1）
(Under optimize conditions)
PC size conveyor
■For 0402, 0603, 1005
36 000 CPH (0.100 s/chip)
■For 0402, 0603, 1005
14 400 CPH (0.250 s/chip)
■For QFP
11 800 CPH (0.305 s/QFP)
M size conveyor
■For 0402, 0603, 1005
34 920 CPH (0.103 s/chip)
■For 0402, 0603, 1005
13 968 CPH (0.258 s/chip)
■For QFP
11 446 CPH (0.315 s/QFP)
Placement accuracy
*1）*2）
(under optimum conditions)
■Placement of 0402, 0603, 1005,
±0.04 mm: Cpk ≧1
■For QFP,
±0.05 mm: Cpk ≧1
(12 12 mm or less)
±0.03 mm: Cpk ≧1
(12 12 to 32 32 mm or less)
■For QFP,
±0.03 mm: Cpk ≧1
Target component
Component dimensions
( 0402 chip)
to 32 32 mm
Component thickness: Max. 12 mm
Component dimensions
( 0603 chip)
to 150 25 mm
(opposite side152.1 mm or less)
Component thickness: Max. 30 mm
Mass: Max. 30 g
PCB change time
4.0 s (Not placed on its reverse side)
4.4 s (Placed on its reverse side)
*1)
The values may vary with the type of component.
*2)
This is the case where the placement angle is 0°, 90°, 180°, or 270°. They may be affected by rapid changes
in ambient temperature.
At
a glance
NPM-TT2 EJM1EE-MB-06O-04
Specifi-
cation
Machine specifications/
Basic performance 2
6-1-1-3
Operating procedure
6-1-1
■Component recognition camera specifications
Basic performance
Item
Multi-recognition camera
*1)
Type 1 (2D measurement)
/ Type 2 (thickness
measurement)
*2)
Type 3 (3D measurement)
Chip Outside dimension
0402 to
QFP
SOP
Outside dimension
5 5 to 45 45 mm
Minimum lead pitch
0.4 mm
Minimum lead width
0.2 mm
BGA
CSP
Outside dimension
5 5 to 45 45 mm
Minimum ball pitch
0.3 mm 0.5 mm
Minimum ball diameter
0.15 mm 0.25 mm
Minimum ball height
--- 0.25 mm
Connector
Outside dimension
to 100 (L) 90 mm (W)
Opposite side134.5mm
Minimum lead pitch
0.5 mm
Minimum lead width
0.2 mm
*1 ) The values may vary depending on head specifications.
*2 ) Thickness can be measured by 0402 to Min Tr/Di.
●Regarding the machines released later than NPM-D3 / NPM-W2 / NPM-TT2 and equipped with multi-
recognition camera, the component library for the conventional line camera may not be partially compatible.
(When the function such as illuminance check of recognition option is used)
NPM-TT2 EJM1EE-MB-06O-04
6-1-1-4
