NPM-TT2 EJM1EE-MB-06O-04
Nozzle specifications 1
6-1-6-1
This machine is equipped with the standard nozzles in each head, supporting many different components.
Common to NPM series.
Operating procedure
6-1-6
Specifi-
cation
8-nozzle head
Nozzle
No.
Shape (mm)
Target
components
(Ex.)
225C
225CN
0603R, C
230C
230CN
1005R, C
1608R, C
240C
240CN
3216R, C
4532R, C
TAN-X,B,C,D
Al electrolytic-
A,B,C
185
185N
SOP
QFP
PLCC
BGA
to 18
× 18 mm
Nozzle
No.
Shape (mm)
Target
components
(Ex.)
140
140N
TAN-D
AI electrolytic-
D
SOP
SOJ
PLCC
CSP
226C
226CN
0603R, C
1005R, C
235C
235CN
1608R, C
2012R, C
3216R, C
SS-Mini Tr, Di
S-Mini Tr, Di
203Z
203ZN
0402R, C
199
199N
SOP
QFP
PLCC
BGA
to 32
× 32 mm
Even though above nine types are standard for
nozzles for 8-nozzle head, they are available as
nozzles for 8-nozzle head in the CM series.
13.8
6
1.5
0.3
13.8
10
1
1
0.1
6
1234
5678
PCB recognition
camera
NOTICE
1.5
13.8
0.3
0.45
0.32
0.17
For the nozzle No. including ‘C’, the nozzle tip is made of ceramic.
For the nozzle No. including ‘N’, the 2D code is provided on the nozzle flange supporting the 2D code
recognition in the NPM series.
.
NPM-TT2 EJM1EE-MB-06O-04
6-1-6-2
1 2 3 4
5 6 7 8
1 2 3 4
5 6 7 8
Pickup component dimensions and nozzle arrangement
( : Pickup enabled, : Pickup disabled)
*When a component exceeds the size of 24 mm 24 mm, install a recognition nozzle of 4mm or less
in nozzle diameter around its nozzle arrangement position.
(Only for transparent recognition)
Pickup enabled component:
12 12 mm or less
(A A 12 12)
Pickup enabled component:
18 18 mm to 24 24 mm
(18 18 < A A 24 24)
Pickup enabled component:
12 12 mm to 18 18 mm
(12 12 < A A 18 18)
1 2 3 4
5 6 7 8
Components of 12 12 mm or less can be
picked up on and .
Recognition nozzle(φ4mm or less): ,
1 2 3 4
5 6 7 8
Pickup enabled component:
Component of 24 24 mm to 28 28 mm
(24 24 < A A 28 28)
Components of 12 12 mm or less can be
picked up on and .
Recognition nozzle(φ4mm or less): , ,
1 2 3 4
5 6 7 8
Pickup enabled component:
Component of 28 28 mm to 32 32 mm
(28 28 < A A 32 32)
At
a glance
NPM-TT2 EJM1EE-MB-06O-04
6-1-6-3
Specifi-
cation
Nozzle specifications 2
Operating procedure
6-1-6
3-nozzle head
Nozzle
No.
Shape (mm)
Target
components
(Ex.)
1001
1001N
1005R, C
1608R, C
2012R, C
SS-Mini Tr, Di
S-Mini Tr, Di
Mini Tr, Di
1003
1003N
AI electrolytic-
AD, E, F
SOP
SOJ
PLCC
BGA
CSP
1005
1005N
SOJ
QFP
PLCC
BGA
Nozzle
No.
Shape (mm)
Target
components
(Ex.)
1599
1599N
0603R, C
1002
1002N
3216R, C
4532R, C
TAN-X, B, C,
D
AI electrolytic-
AA, B, C
1004
1004N
SOP
SOJ
QFP
PLCC
BGA
1006
1006N
This is a nozzle (a reflector)
to be attached to the nozzle
arrangement position not in
use for pickup, depending on
the combination of
components to be picked up.
It enhances the recognition
stability of the head in pickup.
For components
measuring 35 × 35 mm or
larger, a nozzle is attached
to the nozzle position 2.
For components
measuring 63 × 63 mm or
larger, two nozzles are
attached to each nozzle
position 1 and 3.
12
PCB
recognition
camera
3
From a viewpoint of productivity, we recommend
use of 8-nozzle head for 0603 chip for placement.
NOTICE
The nozzle including ‘N’ has the 2D code on the nozzle flange and supports 2D code recognition in the
NPM series.
