NPM- TT2 EJM1EE-BP-02N-01 S-5

NPM-TT2 EJM1EE-BP-01N-04

S-4

Model No.

Mounting heads: 8-nozzle head, 3-nozzle head.

Model No. Position Head Configuration

NM-EJM1E

Front side Mounting head Mounting head No head

Rear side Mounting head No head Mounting head

The Model No. of NPM-TT2 and head configuration are as follows.

Mounting head names

The mounting heads that can be installed to NPM-TT2 consist of 8-nozzle and 3-nozzle heads, each of them

being of two types. The name and product No. of each mounting head are as follows. If the distinction

between 8-nozzle and 3-nozzle heads is not particularly required in the text for the purposes of illustration,

each mounting head is described or referred to as “8-nozzle head” or “3-nozzle head.”

Mounting head Name Product No.

8-nozzle head

Light weight 8-nozzle head N610166414AA

8-nozzle head N610157772AA

3-nozzle head

3-nozzle head V2 MTKA012723AA

3-nozzle head N610157779AA

NPM-TT2 EJM1EE-BP-02N-01

S-5

NPM-TT2 EJM1EE-BP-02N-01

Screen printer

S-6

Flexibility

■Large-size component support

Large components (150 x 25 mm) can be mounted.

(For 3-nozzle head)

■Flexibility in head location

According to the production item, you can select

any combination of placement heads.

Product change, productivity

■Flexible feeder arrangement

You can arrange the feeder anywhere on

the same table.

■Simplified procedure to

attach/detach the feeder cart

The feeder cart can be attached/detached

just with four operations.

Evolve the machine by
