NPM-TT2 EJM1EE-MB-06O-04
6-1-6-4
■Irregular type component nozzle(1/2)
Nozzle No.
1551 / 1551N 1479 / 1479N 2405 / 2405N
Shape
(Unit: mm)
Max.
comp.
weight
0.12 g 3.5 g 1.5 g
Max.
compo.
height
28 mm 25.5 mm 28 mm
Remarks Nozzle length: 22.5 mm
With polyurethane rubber
Nozzle length: 27.5 mm
With polyurethane rubber
Nozzle length: 22.5 mm
Nozzle No.
1404 / 1404N 1421 / 1421N 2467 / 2467N
Shape
(Unit: mm)
Max.
comp.
weight
3.0 g 8.0 g 2.5 g
Max.
compo.
height
28 mm 28 mm 28 mm
Remarks
With polyurethane rubber
Nozzle length: 22.5 mm
With polyurethane rubber
Nozzle length: 22.5 mm
With polyurethane rubber
Nozzle length: 22.5 mm
φ
5
φ
3
φ
5
1
2
3
Polyurethane
rubber
Polyurethane
rubber
5
1.4
3
φ
7
Polyurethane
rubber
φ
10
8
2
4
Polyurethane
rubber
φ
12
10
0.5
2
Polyurethane
rubber
At
a glance
NPM-TT2 EJM1EE-MB-06O-04
6-1-6-5
Specifi-
cation
Nozzle specifications 3
Operating procedure
6-1-6
Nozzle No.
1115 / 1115N 2405 / 2405N 1424 / 1424N
Shape
(Unit: mm)
Max.
comp.
weight
2.0 g 1.5 g 4.8 g
Max.
compo.
height
28 mm 28 mm 28 mm
Remarks Nozzle length: 22.5 mm
With polyurethane rubber
Nozzle length: 22.5 mm
With polyurethane pad
Nozzle length: 22.5 mm
■Irregular type component nozzle (2/2)
Nozzle No.
1427 / 1427N 2421 / 2421N
Shape
(Unit: mm)
Max.
comp.
weight
9.7 g 14.5 g
Max.
compo.
height
28 mm 28 mm
Remarks
With polyurethane pad
Nozzle length: 22.5 mm
With polyurethane pad
Nozzle length: 22.5 mm
Pad φ3.5
Polyurethane
rubber
φ
1
φ
1.6
Pad φ3.5
15
20
6
Pad φ3.5
NPM-TT2 EJM1EE-MB-06O-04
6-1-6-6
1 2 3
■Operation standard of pickup depth and nozzle length of an electric component
Required nozzle length may vary depending on pickup depth of an electric component
(distance from a top surface of embossed tape to a pickup surface of an electric
component.)
Pickup
depth B
0 to 3 mm or
less
3 to 8 mm or
less
8 to 13mm or
less
Nozzle
length A
22.5 mm 27.5 mm 32.5 mm
Embossed tape
Component
Nozzle length A
Pickup depth B
●Pickup enabled component:
Diagonal 41 mm(29 29 mm)
*1）
or less and L
35 mm or less
Diagonal 47 mm(33 33 mm)
*1）
or less and L
38 mm or less and t≦14 mm or less
●Pickup enabled component:
Diagonal 76 mm(54 54 mm) or less
and L 65 mm or less
■Pickup component dimensions and nozzle arrangement
( ●: Pickup enabled, ○: Pickup disabled, : #1006 nozzle (Reflector)
*2）
1 2 3
1 2 3
●Pickup enabled component:
Diagonal 152.1 mm or less and L 150 mm or
less and W 90 mm or less
At
a glance
*1) Numerical value in ( ) is an example in the case of L=W.
When pickup position is offset from the center of the component, the component size has restrictions.
Please ask us for details.
*2) Please install #1006 nozzle (reflector) according to the component’s size or shape.
