2 Preparation
NPM-TT2 EJM1EE-MB-02O-04
SERVO
ON
3
●Wait for 2 to 3 minutes after turning
ON the main power switch. (Once
the system starts, the screen below
is displayed)
2
2-1-1-1
●Keep the main power switch in
the OFF state for over 10 seconds
when turning it ON.
The emergency stop switch is released.
●Make sure that any risk
or trouble is eliminated
and then turn the
emergency stop switch
right to release it.
1
No foreign material is present on the conveyor or the
feeder table.
The safety covers are closed.
1
3
4
Front side
5
The main pressure is appropriate.
(→[Maintenance] P.4-1-1)
Basic
opera-
tion
Starting and stopping
the machine
Operating procedure
2-1-1
Starting the machine
OFF
SERVO
Checks before operation
The servo switch is turned OFF.
2
SERVO
ON
NPM-TT2 EJM1EE-MB-02O-04
1
2-1-1-2
Stopping the machine
Return all axes
to the origin
(→[Operating procedure]
P.5-2-1)
●Lock the machine after
turning OFF the main
power switch.
2
Preparation
