NPM- TT2 EJM1EE-MB -02O-04 2-2-1 -10 Preparatio n

NPM-TT2 EJM1EE-MB-02O-04

2-2-1-9

Compo-

nent

names

Touchscreen 5

Operating procedure

2-2-1

Choosing the dual conveyor enables you to switch the lane between 1 and 2.

Lane switch button

●Every time you pressed, the mode

switches.

:Lane 1

:Lane 2

●If the button is not activated or the

production data is installed only for one

lane, it does not switch.

NPM-TT2 EJM1EE-MB-02O-04

2-2-1-10

Preparation

NPM-TT2 EJM1EE-MB-02O-04

2-2-2-1

Operator mode 1

Changes the operation mode.

Operation mode change

Home menu

Compo-

nent

names

Menu configuration 1

Operating procedure

2-2-2

Remaining monitor

Checks information on the component shortage of each table in line.

Checks pickup status.

Pickup monitor

Status monitor

Displays production information during operations, parts shortages and

other status.

First layer Second layer Third layer Fourth layer

Production start

Starts automatic production.

Adjustment soft switch

Temporarily changes the operating environment to debug the machine.

Production

(before

production)

*1)

*2)

*1)

*2)

Production

(during

production)

*1)

*2)

*1)・For single lane mode

・For alternate mode on the dual lane mode

*2)・For independent mode on the dual lane mode
