Consumables, Spare and Wear Parts, Tools
Minor and Major Maintenance for CPP, C&P6/12, C&P20A and TwinHead
24 Maintenance Manual SIPLACE X Series
Wear parts Item No. Supplied in
starter kit
03071171
-
03
CPP CP20A TH CP6/12
Nozzles 20xx, 28xx According to
configuration
X
Pipetten 7xx / 9xx According to
configuration
X
Ceramic nozzles 20xx / 28xx According to
configuration
X
Ceramic nozzles 7xx / 9xx / 30xx According to
configuration
X
Filter disk assembly / CPP 03049943-xx X X
Hose DP / CPP 03015920Sxx X X
DIN 913 - M 4 x 4-A2 (grub screw) 00323430-xx X X
Pipetten 10xx / 12xx According to
configuration
X
Ceramic nozzles 10xx / 12xx According to
configuration
X
Filter disk assembly, C&P20 03042001-xx X X
Switching disk assembly/DP C&P20 03013091-xx X X
Replacement filter FE 50 03047489-xx X
Silencer for C&P head 03003134-xx X
Valve plunger C&P6 (6 in one pack) 00351500-xx X
Valve plunger C&P12 (6 in one pack) 00351498-xx X
O-ring for valve plunger 00359382-xx X
O-ring for distributor 8*1 NBR 70 B 00201179-xx X
O-ring vacuum distributor 3*1,2 NBR
70 B
00320057-xx X
O-ring vacuum generator 10*1,5 NBR
70 B
00320047-xx X
O-ring vacuum generator 14*1,5 NBR
70 B
00320048-xx X
O-ring vacuum generator 8*1 Viton 75 00350661-xx X
O-ring vacuum generator 10*1 Viton
75
00350662-xx X
O-ring vacuum generator 30*1
(vacuum pump operation)
00343022-xx X
Synchroflex toothed belt 2.5 T2/90
(turning station)
00320041-xx X
O-ring turning station 16*2 E 70 B 00320043-xx X
Toothed belt T2/DLM1 (Z axis DLM) 00334936-xx X
Vacuum nozzle diameter 1.5 00319420-xx X
Vacuum nozzle diameter 1.0 00319423-xx X
Suction plate assembly for sleeve,
blue
03037984Sxx X
Component sensor protective cap 03080984-xx X
Consumables, Spare and Wear Parts, Tools
Minor and Major Maintenance for CPP, C&P6/12, C&P20A and TwinHead
Maintenance Manual SIPLACE X Series 25
Tools Item No. Supplied in
starter kit
03071171
-
03
CPP CP20A TH CP6/12
ESD wriststrap TYP.OK/WRS 00320279-xx X X X X
Universal head stand 00363290-xx X X X X
Multipipette Plus 4981 03078989-xx X X X
Combitips Plus 0.2 ml blue 03070440-xx X X X
Combitips Plus 0.1 ml black 03078990-xx X X X
Combitips Plus 0.1 ml yellow 03077923-xx X X
Combitips Plus 0.1 ml green 03077924-xx X X
Combitips Plus 0,1 ml withe
(only for C&P20)
00386155-xx X X
Silicon hose D12 L20mm 03058392-xx X X
Protective hose for component sensor
C&P20
03078596-xx X X
Filter disk extraction device /C&P20 03055046-xx X X
Lubrication application tool for star
bearing CPP
03078632-xx X X
Clamping ring mount front plate CPP 03077754-xx X X
Antistatic tweezers, type Bernstein
5
-
192
00377393-xx X X X X
Antistatic tweezers, type Bernstein
5
-
195
00377394-xx X X X X
TorqueVario-S screwdriver (100-500
cNm)
03078400-xx X X X X X
Bit holder for TorqueVario screwdriver 03078706-xx X X X X
Extension / straight TX20 03073256-xx X X X X X
Extension / straight 03043440-xx X X X X X
Extension / with joint (170 x SK3) 03042635-xx X
Hexagon socket head cap screw
driver 0.7-2
00320265-xx X X X X
Torx Allen screwdriver TX8 03080081-xx X X X X
Open-jawed spanner, size 10 X
Nozzle assembly type 1235 03015222-xx X X
Calibration tool version 3 03010565-xx X X X
Calibration tool version SST23 03034148-xx X X X X
Long-nosed pliers X
Nozzle / Zero-point correction
TwinHead
(not necessary from SW705.03)
03008862-xx X X
Nozzle assembly type 518 / TwinHead 03012011-xx X X
Nozzle assembly type 517 / TwinHead 03012042-xx X X
Pipette Typ 2057 kpl. 03070280-xx X X
Plastic box 48x48x19 00384335-xx X X X
Consumables, Spare and Wear Parts, Tools
Minor and Major Maintenance for CPP, C&P6/12, C&P20A and TwinHead
26 Maintenance Manual SIPLACE X Series
Plastic box 36x36x12 00384333-xx X X X
Case with inlay 03078708-xx X X X X
Brief maintenance guide C&P20/
C&P20A/CPP
00196606-xx X X X
Set of Allen wrenches 00376492-xx X X X
Set of Phillips screwdrivers 00319064-xx X
Plastic brush Dm 8 00325866-xx X X X
Cartridge rack 10xx
(CPP, C&P20, DLM4)
03071700-xx X X X
Guiding plate 10xx/20xx long
(CPP, C&P20, DLM4)
03066508-02 X X X
Guiding plate for cleaning box DLM3 03029178-xx X
Cleaning box for ceramic nozzles, type
10xx / long
03055736-xx X
Maintenance manual C&P20, DE 00196383-xx X
Maintenance manual C&P20, EN 00196384-xx X
Cleaning cartridge for ceramic
nozzles, type 20xx / long
03076627-xx X
Component sensor protective cap 03080984-xx X
Brush 00378523-xx X
Angled tweezers 00096487-xx X
SPIRAL drill cylinder R.1.4 D DIN 338 00092026-xx X
Spiral drill cylinder R.1.1 D DIN 338 00092020-xx X
Oil dispenser Z axis with STRUCTVIS
GHD 7 ml
00367071-xx X
Plunger maintenance tool 03049689-xx X
Cleaning tools for encoder disk 03049704Sxx X
Sleeve cleaning device 00377260-xx X
Pliers for fitting plastic hose 2MS-PK-
3/4
00346929-xx X
Cleaning cartridge 9xx
(for DLM3, DLM4 snapping on
manually)
03003183-xx X
Cleaning cartridge 30xx
(for DLM4, DLM3 snapping on
manually)
X
Tools Item No. Supplied in
starter kit
03071171
-
03
CPP CP20A TH CP6/12
