Error ID Item Description
400305 Load Power Circuit The fdr.crg. axis safety guard (a) is open.
400306 Load Power Circuit The fdr.crg. axis safety guard (b) is open.
(Cause 1) The feeder work area safety door was opened.
(Remedy 1) Close the feeder work area safety door after pressing the [RETURN] button and
zero all axes. Then, re-start the operation.
400307 Load Power Circuit Load power-on timeout.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
400401 Load Control Power Circuit
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
400501 Lightning Surge Warning Lightning Surge Protector works; Q204. Load power on with
reset operation.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
410101 PLACEMENT NOZZLE APPROPRIATE NOZZLE MISSING.
Cause 1) A nozzle different from the nozzle-related data is attached.
(Remedy 1) Check the attached nozzle and the "Nozzle Data" window (described in "4. Nozzle
Data" in "Section 5 (Vol. 3: Programming and Machine Data)" and reset the ma
chine to its normal condition.
.
410201 Alternate Mode Available fdr.carriage is not found.
(Cause 1) A wrong parameter is set in the "Alternate" tab sheet.
(Remedy 1) Check the carriage to be used and correct the wrong parameter if any.
3.3 Error IDs and Remedial Procedures
0307-005 2-92 AGS01ETRP
Error ID Item Description
410301 Current Pattern Program
No Exist
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Perform a program change operation.
When the program change operation cannot be performed, contact our service
personnel.
410401 Component Cannot refer to component data.
(Cause 1) A mistake is found in the placement feeder location data of the pattern program data.
(Remedy 1) Check the placement feeder location data. If necessary, correct the mistake.
410501 Placement Data Already placed
410502 Placement Data Placement step missing. Start and recovery with WARM
START.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Follow the described instructions and reset the machine to its normal condition.
410601 Component Data Available nozzle is not found.
410701 Nozzle Type
(Cause 1) A correct nozzle may not be attached or the attached nozzle may not conform to the
placement head/nozzle data and the nozzle type data.
(Remedy 1) Check the nozzle attached to the head of the machine.
Refer to the "4. Nozzle Data" in "Section 5 (Vol. 3: Programming and Machine
Data)" and check the placement head/nozzle data and the nozzle type data.
410801 Current Pattern Program
No Exist
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Perform a program change operation.
When the program change operation cannot be performed, contact our service
personnel.
410901 PEC Inspect Data Overflow P.E.C. inspect data count.
(Cause 1) The pattern program data is wrong.
(Remedy 1) Create a correct pattern program.
3.3 Error IDs and Remedial Procedures
0307-005 2-93 AGS01ETRP
Error ID Item Description
420101 Input Buffer Cnvr. Overtime P.C.B. from inp. machine was not received.
420102 Input Buffer Cnvr. Overtime P.C.B. on inp.buffer cnvr. was not able to move to its outlet.
(Cause 1) The P.C.B. is trapped on the conveyor.
(Cause 2) An operator removed the P.C.B. in the middle of transfer.
(Remedy 1) The conveyor width may not be adjusted correctly or the P.C.B. size may be
different.
Readjust the conveyor width or confirm if the P.C.B. size is proper or not.
(Remedy 2) Place the P.C.B. back in position and re-start the automatic operation.
420201 Input Cnvr. P.C.B. Overtime P.C.B. on input cnvr. was not able to move to its outlet.
(Cause 1) The light emitted from the P.C.B. detection photosensor on the L2 conveyor is re-
ceived or not.
Dirt may have adhered to the sensor.
(Cause 2) The P.C.B. transfer detection photosensor on the L2 conveyor is defective.
(Remedy 1) Check if the light emitted from the P.C.B. detection photosensor can be received
or not.
(Remedy 2) Contact our service personnel for details.
420202 Input Cnvr. P.C.B. Overtime P.C.B. from inp. buffer cnvr. was not received.
(Cause 1) The light emitted from the P.C.B. detection photosensor on the L1 conveyor is re-
ceived or not.
Dirt may have adhered to the sensor.
(Cause 2) The set value for Input Output Conveyor Timer 2 or Output Conveyor Timer 2 has
exceeded the range of setting.
(Cause 3) The P.C.B. transfer detection photosensor on the L1 conveyor is defective.
(Remedy 1) Check if the light emitted from the P.C.B. detection photosensor on the L1 con-
veyor can be received or not.
(Remedy 2) Correct the set value for Input Conveyor Timer 2 or Output Conveyor Timer 2.
(Remedy 3) Contact our service personnel for details.
3.3 Error IDs and Remedial Procedures
0307-005 2-94 AGS01ETRP
