3.3 Error IDs and Remedial Procedures
Error ID ltem Description
470801 Comp. Thickness(Sensor)
(Cause 1) The machine stopped running because the linear measure detection sensor de-
tected the "Component Thickness Error (Sensor)" error continuously.
Ref.: When "9" is set in the "2" text box of "Error process" in the component library
data, it means that a pick-up error occurred continuously 9 times on the same
feeder No.
(Remedy 1) Follow the steps below to reset the machine to the normal condition.
(1) Check "Step" and "Feeder No." where an error has occurred.
(2) Press the [RETURN] and [ALL] button (entitled "ZERO"). After that, check
the following items related to the pertinent feeder No.
• Check if the tape feeder is loaded with correct components.
• Check the selected components and the component library data.
If wrong parameters are set in the component library data, correct them.
Note: Check the parameter set as component thickness check data in
the "CMPNT CARRIAGE DATA EDIT" window.
(3) After taking the required countermeasures, re-start the production.
470901 Cancel Recovery On
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0307-006 2-113 AGS01ETRP
Error ID ltem Description
470a01 Auto Recovery Pause Attach the new comp. And press [READY]. Then, press
[START] button to re-start.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Follow the described instructions and reset the machine to its normal condition.
480101 DEVICE INSPECT Failed in Issuing the Lighting Selection Command.
480102 DEVICE INSPECT Error Response of Lighting Selection Command!
480103 DEVICE INSPECT Delayed Response of Lighting Selection Command!
480104 DEVICE INSPECT Failed in Issuing the Image Capture Command.
480105 DEVICE INSPECT Error Response of Image Capture Command!
480106 DEVICE INSPECT Failed in Issuing the Recognition Command.
480107 DEVICE INSPECT Delayed Response of Image Capture Command!
480108 DEVICE INSPECT Error Response of Recognition Command!
480109 DEVICE INSPECT Error Response of Recognition Command (Delayed Recogni
tion)!
48010a DEVICE INSPECT Error in Recognition-Related Data Transfer!
48010b DEVICE INSPECT Failed in Issuing the Recognition Interrupt Command.
48010c DEVICE INSPECT Error Response of Recognition Interrupt Command!
48010d DEVICE INSPECT Time-Out of Recognition Interrupt Processing
48010e DEVICE INSPECT Time-Out of Lighting Selection Processing
48010f DEVICE INSPECT Time-Out of Recognition ON Response
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-006 2-114 AGS01ETRP
Error ID ltem Description
490101 CPU1 Board Error in an internal communication interruption program. Please
turn off a breaker.
490102 CPU1 Board Error in an internal data reception program. Please turn off a
breaker.
490103 CPU1 Board Error in an internal data transmitting program. Please turn off
a breaker.
490201 CPU2 Board
490202 CPU2 Board Memory allocation error.
490203 CPU2 Board System error occurred.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
490301 Recognition Board Recognition board was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
490401 HLSC2 Board HLSC2 board was not detected.
490402 HLSC2 Board H1 board was not detected.
490403 HLSC2 Board System error occurred.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-006 2-115 AGS01ETRP
