Error ID ltem Description
4b0308 ILLEGAL OPERATION P.C.B. WAS TOOK ON INPUT BUFFER CONVEYOR.
Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b0309 ILLEGAL OPERATION P.C.B. WAS TOOK ON INPUT CONVEYOR.
(Cause 1) An improper P.C.B. exists on the transfer conveyor.
(Remedy 1) Remove the improper P.C.B. on the transfer conveyor and re-start the production.
4b030a ILLEGAL OPERATION P.C.B. WAS TOOK ON OUTPUT CONVEYOR.
(Cause 1) An improper P.C.B. exists on the output conveyor.
(Remedy 1) Remove the improper P.C.B. on the output conveyor and re-start the production.
4b030b ILLEGAL OPERATION P.C.B. REMOVE FROM INPUT BUFFER CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b030c ILLEGAL OPERATION P.C.B. REMOVE FROM INPUT CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-004 2-121 AGS01ETRP
Error ID ltem Description
4b030d ILLEGAL OPERATION P.C.B. REMOVE FROM OUTPUT CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b0401 Machine Interface Signal Check the P.C.B. input machine on conveyor. Input machine
P.C.B. existence signal turn to available for setup.
4b0402 Machine Interface Signal Check the P.C.B. output machine on conveyor. Output ma-
chine P.C.B. existence signal turn to available for setup.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4c0101 B.B.R. All unit P.C.B.’s were detected as defective. (P.C.B. on
XY-Table)
4c0102 B.B.R. All unit P.C.B.’s were detected as defective. (P.C.B. on
Transfer Conveyor)
4c0201 Unit P.C.B. B.B.R. Information Not exist available information. (P.C.B. on Transfer Conveyor)
4c0202 Unit P.C.B. B.B.R. Information Not exist available information. (P.C.B. on XY-Table)
4c0203 Unit P.C.B. B.B.R. Information Communication data is illegal information.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Follow the described instructions and reset the machine to its normal condition.
3.3 Error IDs and Remedial Procedures
0307-004 2-122 AGS01ETRP
Error ID ltem Description
4f0101 PROGRAM ERROR Error in Sequence Controller! Operation Not Secured
4f0201 PROGRAM ERROR Error in Polling Task (CPU2)! Operation Not Secured
4f0202 PROGRAM ERROR Error in Polling Task (CPU3)! Operation Not Secured
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
500101 Comp. Missing (Sensor)
500201 Comp. Vertical (Sensor)
500301 Comp. Missing (Recog.)
500401 Comp. Recog. Error
500501 Shortage of Comp. Attach the new comp. And press [READY]. Then, press
[START] button to re-start.
500601 Group Chip Remove this component. Then, press [START] button to re-
start.
500701 Comp. Thickness (Sensor)
500801 Comp. Pickup Diff. (recog.)
500901 Comp. Reverse (recog.)
500a01 Alternate Feeder Disable Enable alt. And press [READY] button. Then, press [START]
to re-start.
500b01 Cancel Recovery On
500c01 Auto Recovery Pause Attach the new comp. And press [READY]. Then, press
[START] button to re-start.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-005 2-123 AGS01ETRP
