Error ID ltem Description
610206 Nozzle Skip Nozzle Level
(Cause 1) This error occurs when the L value exceeds the tolerance in comparison with the
master nozzle in the offset data.
(Remedy 1) Check if a big value is set as an L level of the master level in the offset data.
Check if the nozzle is broken or dirt adheres to the end.
610207 Nozzle Skip Nozzle Drop
(Cause 1) When a "NOZ. DOWN ERR (L)" error occurs, the nozzle is bypassed and the nozzle
bypass data indicates that "BYPASSED" appears as a low nozzle item.
(Remedy 1) Open the "Head/Noz. Bypass" tab sheet in the "OPN. MODE" window (submenu)
and press the [Reset Noz. Bypass] button. The "Bypass" in the "Nozzle Height"
text box disappears, indicating that "Bypass" is canceled.
610208 Nozzle Skip Dummy Nozzle
610209 Nozzle Skip Manual Bypass
(Cause 1) This appears when some nozzles are bypassed manually.
(Remedy 1) When the [Reset Noz. Bypass] button is pressed in the "Head/Noz. Bypass" tab
sheet of the "OPN. MODE" window (submenu), the manual bypass designation of
all nozzles is all canceled.
61020a Nozzle Skip Nozzle Change Error. (Cam lock action)
61020b Nozzle Skip Nozzle Change Error. (Cam Free action)
61020c Nozzle Skip Cam Origin Error.
61020d Nozzle Skip Nozzle Teach Error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0307-005 2-129 AGS01ETRP
Error ID ltem Description
610301 Head Skip Communication Error
610302 Head Skip Head Origin
610303 Head Skip Overtime Head Origin Return
610304 Head Skip Unselected Nozzle Drop
610305 Head Skip Dummy Nozzle
610306 Head Skip Manual Bypass
610307 Head Skip Alarm Error
(Cause 1) Self-Diagnostics Error Message
(Cause 2) The voltage of the stabilization power supply unit (PSU) is abnormal.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Consult our service personnel for details.
610401 Nozzle Level Nozzle Level (Low) Was More Than Tolerance.
610402 Nozzle Level Nozzle Level (Low) Was Less Than Tolerance.
610403 Nozzle Level Nozzle Level (High) Was More Than Tolerance.
610404 Nozzle Level Nozzle Level (High) Was Less Than Tolerance.
(Cause 1) This error occurs when there is a big difference in nozzle levels in comparison with
the master nozzle during teaching operation.
(Remedy 1) Re-teach the data of the master nozzle.
610501 Master Head Offset Linear Masure System Was At High Position.
610502 Master Head Offset Linear Masure System Was At Low Position.
(Cause 1) The master nozzle or the linear measure detection sensor may not be attached
correctly.
(Remedy 1) Attach the master nozzle correctly.
It is required to adjust the linear measure detection sensor after it is attached
correctly.
3.3 Error IDs and Remedial Procedures
0307-005 2-130 AGS01ETRP
Error ID ltem Description
610601 Head Origin Offset Total Designate Loop Exceeded Time.
(Cause 1) Each head deviated from its origin position in comparison with the master head.
(Remedy 1) Check if the master head is not loose.
610701 Comp. Thickness Teach Component Thickness Was Less Than Tolerance.
610702 Comp. Thickness Teach Component Thickness Was More Than Tolerance.
(Cause 1) A mistake is found in the component thickness data of the component library data.
(Remedy 1) Set the component thickness data correctly.
610801 Recog. Data Teach Recognition Error Code.
610901 Trash Teach Error Code. Trash Teach Error Code.
610a01 Gain Level Teach Error Trash Teach Error Code.
Note: Refer to "4. Troubleshooting on Recognition System" for details.
3.3 Error IDs and Remedial Procedures
0307-004 2-131 AGS01ETRP
