4.3 Recognition Error IDs and Remedial Procedures Recognition Error ID Item Description 02**2201** Error in Lead Inspection The number of leads is incorrect. 02**2202** Error in Lead Inspection The number of leads is sma…

(a) Error IDs "*" will be filled with primary error classification

and detail codes.

(b) When an error ID other than the described ones is issued,

contact our service personnel for some advice.

Table 4B11

Recognition Error ID Item Description

02**1000** Component Missing Component was not found.

(Cause 1) The feeder carriage is loaded with a feeder that contains components dif-

ferent from the specified ones.

(Cause 2) The vacuum suction force is too weak.

(Cause 3) An improper nozzle is selected for the components or vice versa.

Mismatching parameters are set in the nozzle type data and the compo-

nent library data.

(Remedy 1) Check if proper components are used.

(Remedy 2) Check the vacuum pressure.

(Remedy 3) Check the parameters in the nozzle type data and the component li-

brary data.

02**2101** Error in Outward Length Inspection Cmponent Outward Length X is incorrect.

02**2102** Error in Outward Length Inspection Component Outward Length X is shorter than the

tolerance.

02**2103** Error in Outward Length Inspection Component Outward Length X is longer than the

tolerance.

02**2104** Error in Outward Length Inspection Component Outward Length Y is incorrect.

02**2105** Error in Outward Length Inspection Component Outward Length Y is shorter than

the tolerance.

02**2106** Error in Outward Length Inspection Component Outward Length Y is longer than the

tolerance.

02**2107** Error in Outward Length Inspection Component Outward Length X or Y is incorrect.

02**2108** Error in Outward Length Inspection Component Outward Length X or Y is shorter

than the tolerance.

02**2109** Error in Outward Length Inspection Component Outward Length X or Y is longer than

the tolerance.

(Cause 1) Wrong parameters are set in the "X [mm]" and "Y [mm]" text boxes of

"Mold size" and the "Mold size tolerance X [mm]" and "Mold size tolerance

Y [mm]" text boxes for the selected components.

(Remedy 1) Check the selected components and the parameters set in the "X [mm]"

and "Y [mm]" text boxes of "Mold size" and the "Mold size tolerance X

[mm]" and "Mold size tolerance Y [mm]" text boxes for the selected

components in the component library data.

Correct wrong parameters if they are set in the component library data.

4.3 Recognition Error IDs and Remedial Procedures

Fig. 4B20

0307-005 2-187

AGS01ETRP

4.3 Recognition Error IDs and Remedial Procedures

Recognition Error ID

Item Description

02**2201** Error in Lead Inspection The number of leads is incorrect.

02**2202** Error in Lead Inspection The number of leads is small.

02**2203** Error in Lead Inspection The number of leads is large.

02**2204** Error in Lead Inspection The lead width is incorrect.

02**2205** Error in Lead Inspection The lead width is shorter than the tolerance.

02**2206** Error in Lead Inspection The lead width is longer than the tolerance.

02**2207** Error in Lead Inspection The lead length is incorrect.

02**2208** Error in Lead Inspection The lead length is shorter than the tolerance.

02**2209** Error in Lead Inspection The lead length is longer than the tolerance.

02**2210** Error in Lead Inspection The lead pitch is incorrect.

02**2211** Error in Lead Inspection The lead pitch is smaller than the tolerance.

02**2212** Error in Lead Inspection The lead pitch is larger than the tolerance.

02**2213** Error in Lead Inspection The lead position (LATL DIR) is incorrect.

02**2214** Error in Lead Inspection The lead position (LONG DIR) is incorrect.

(Cause 1) The results of the lead inspection differ from the parameters specified in the

component library data for the selected components.

(Remedy 1) Check the leads of the selected component and the component library

data.

Correct wrong parameters if they are set in the component library data.

0307-004 2-188 AGS01ETRP

4.3 Recognition Error IDs and Remedial Procedures

Recognition Error ID

Item Description

02**2301** Error in Electrode (Ball) Inspection The Electrode(ball) position is incorrect.

02**2302** Error in Electrode (Ball) Inspection There is Electrode(ball) of the size outside per-

missible value.

(Cause 1) There is a difference between the results of the electrode (ball) inspection

of the selected component and the component library data.

(Remedy 1) Check the electrodes (balls) of the selected component and the compo-

nent library data.

Correct wrong parameters if they are set in the component library

data.

02**2401** Error in Polarity Detection. Failed in Polarity Detection.

02**2402** Error in Polarity Detection. The detected polarity differs from specification.

(Cause 1) There is a difference between the results of the polarity determination of the

selected component and the component library data.

(Remedy 1) Check the polarity of the selected component and the component library

data.

Correct wrong parameters if they are set in the component library

data.

02**2901** Picked Posture Error The pick angular skew is big.

02**2902** Picked Posture Error The pick-up position has deviated greatly in X di-

rection.

02**2903** Picked Posture Error The pick-up position has deviated greatly in Y di-

rection.

02**2904** Picked Posture Error The pick-up position has deviated greately in X or

Y direction.

(Cause 1) When a component is picked up, the pick-up positions (X and Y) and angle

have shifted greatly from the correct ones.

(Cause 2) When the tape is fed, a component is turned vertically.

(Remedy 1) Check the selected component and the tape feeder.

Check if the feeder (B) offset data is correct.

Check if the component library data is correct.

(Remedy 2) Check the selected component and the tape feeder.

0307-005 2-189 AGS01ETRP
