Recognition Error ID Item Description
02**3401** Error in Line Detection Some linear edges cannot be detected because
they are hidden by the nozzle.
02**3402** Error in Line Detection No linear edge detected.
02**3403** Error in Line Detection The detected linear edge position does not match
the position data.
(Cause 1) There is a difference between the results of the line inspection of the se-
lected component and the component library data.
(Remedy 1) Check the line of the selected component and the component library
data. If wrong parameters are set in the component library data, correct
them.
02**3501** Error in Lead Detection Some leads cannot be detected because they
are hidden by the nozzle.
02**3502** Error in Lead Detection No Lead Detected.
02**3503** Error in Lead Detection Corner of Leads Not Detected.
02**3504** Error in Lead Detection Ends of Leads Not Detected.
02**3505** Error in Lead Detection Ends of Arrayed Leads Not Detected.
02**3506** Error in Lead Detection Lead Edges of Corner Not Detected.
02**3507** Error in Lead Detection Leads of Corner Not Detected.
02**3508** Error in Lead Detection The number of leads at the detected corner is
smaller than the set value.
02**3509** Error in Lead Detection Incorrect Lead-to-Lead Distance at Detected Cor-
ner.
02**3510** Error in Lead Detection Incorrect Lead-to-Lead Angle at Detected Cor-
ner.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
4.3 Recognition Error IDs and Remedial Procedures
0307-005 2-192 AGS01ETRP
Recognition Error ID Item Description
02**3512** Error in Lead Detection The detected number of leads is smaller than
the set value.
02**3513** Error in Lead Detection The detected number of leads is larger than the
set value.
02**3515** Error in Lead Detection The detected lead position does not match the
position data.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
02**3601** Error in Electrode(ball) Detection No Electrode(ball) Detected.
02**3602** Error in Electrode(ball) Detection Since a sufficient number of Electrode(ball) were
undetectable, it cannot position.
02**3603** Error in Electrode(ball) Detection There is Electrode(ball) undetectable in the line or
sequence of a group outside.
02**3604** Error in Electrode(ball) Detection Electrode(ball) which is in agreement with data
was undetectable.
02**3605** Error in Electrode(ball) Detection Electrode(ball) which is not specified was detected.
(Cause 1) There is a difference between the results of the electrode (ball) inspection of
the selected component and the component library data.
(Remedy 1) Check the electrodes (balls) of the selected component and the compo-
nent library data.
Correct wrong parameters if they are set in the component library
data.
02**4101** Reverse Check Error The component is reversed.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
4.3 Recognition Error IDs and Remedial Procedures
0307-005 2-193 AGS01ETRP
Recognition Error ID Item Description
02**4201** Error in Pick-up Position The pick-up position has deviated greatly in X
Detection. direction.
02**4202** Error in Pick-up Position The pick-up position has deviated greatly in Y
Detection. direction.
02**4203** Error in Pick-up Position The pick angular skew is big.
Detection.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
02**8001** Data Error Data Error in Process
02**8002** Data Error Error in Lighting Data
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
02**9001** Other Errors Internal Processing Error
02**9002** Other Errors Impossible to set the detection window.
02**9003** Other Errors Impossible to set the window for arrayed lead end
detection.
02 **9004** Other Errors Impossible to set the window for lead detection at
the corner.
02**9005** Other Errors Impossible to set the window for lead detection.
02**9006** Other Errors Angle Calculation Impossible.
02**9007** Other Errors Internal Processing Error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
4.3 Recognition Error IDs and Remedial Procedures
0307-005 2-194 AGS01ETRP
