0307-004 2-201 AGS01ETRP
Recognition Error ID Item Description
10040***9* ---- Error in Teaching Data
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Perform the teaching operation again.
100401**01 ---- Component recognition camera dirt detection er-
ror. Dirt has been detected on recognition camera
lens or placement head lighting diffuser.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Wipe the cover glass or the diffusion plate with a soft cloth.
100401**02 ---- Component recognition camera dirt detection er-
ror. Abnormalities are in the lighting method, light-
ing intensity data, and gain level data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode, the lighting intensity, and the gain & level data.
100402**01 ---- Nozzle dirt detection error. Dirt has been detected
on pick-up nozzle or placement head lighting dif-
fuser.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Wipe the diffusion plate or the end and tapered area of the vacuum nozzle
with a soft cloth.
100402**02 ---- Nozzle dirt detection error. Abnormalities are in
the lighting method, lighting intensity data, and
gain level data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode, the lighting intensity, and the gain & level data.
4.3 Recognition Error IDs and Remedial Procedures
0307-004 2-202 AGS01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID Item Description
100403**01 ---- Error in lighting check. Abnormalities are in the
lighting method and gain level data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode and the gain & level data.
100403**1* ---- Error in lighting check. It is not in the assumed
lighting state.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Make the dirt and dust inspection (the diffusion plate or the nozzle) and
confirm that no dirt and dust have accumulated.
100404**01 ---- Error in gain level teaching. Since it is too dark, it
cannot teach.
100404**02 ---- Error in gain level teaching. Since it is too bright,
it cannot teach.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting intensity data.
100404**03 ---- Error in gain level teaching. A gain or level data is
not suitable.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode and the gain & level data.
100404**1* ---- Error in gain level teaching. It is not in the as-
sumed lighting state.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Make the dirt and dust inspection (the diffusion plate or the nozzle) and
confirm that no dirt and dust have accumulated.
0307-004 2-203 AGS01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID Item Description
1005012001 ---- Specified Number of Dots Not Found during Cam-
era Angle Teaching Operation
(Cause 1) The jig is not correctly set.
(Cause 2) A foreign substance adheres to the jig.
(Remedy 1) Set the jig correctly.
(Remedy 2) Wipe the jig surface with a soft cloth.
