0307-004 2-202 AGS01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID Item Description
100403**01 ---- Error in lighting check. Abnormalities are in the
lighting method and gain level data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode and the gain & level data.
100403**1* ---- Error in lighting check. It is not in the assumed
lighting state.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Make the dirt and dust inspection (the diffusion plate or the nozzle) and
confirm that no dirt and dust have accumulated.
100404**01 ---- Error in gain level teaching. Since it is too dark, it
cannot teach.
100404**02 ---- Error in gain level teaching. Since it is too bright,
it cannot teach.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting intensity data.
100404**03 ---- Error in gain level teaching. A gain or level data is
not suitable.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode and the gain & level data.
100404**1* ---- Error in gain level teaching. It is not in the as-
sumed lighting state.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Make the dirt and dust inspection (the diffusion plate or the nozzle) and
confirm that no dirt and dust have accumulated.
0307-004 2-203 AGS01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID Item Description
1005012001 ---- Specified Number of Dots Not Found during Cam-
era Angle Teaching Operation
(Cause 1) The jig is not correctly set.
(Cause 2) A foreign substance adheres to the jig.
(Remedy 1) Set the jig correctly.
(Remedy 2) Wipe the jig surface with a soft cloth.
4.3.6 Component Recognition Lighting Lamp Burnout Errors
AA BB C DDDDD
Detail Code
Secondary Error Classification (0)
Primary Error Classification (0)
Classification (13) of Recognition Functions
Table 4B15
Recognition Error ID Item Description
1300000000 ---- The lamp for back lighting has blown in the com-
ponent recognition lighting unit.
1300000001 ---- The lamp for Front Lighting 1 (Ring 1) has blown in
the component recognition lighting unit.
1300000002 ---- The lamp for Front Lighting 2 (Coax) has blown in
the component recognition lighting unit.
1300000003 ---- The lamp for Front Lighting 3 (Ring 2) has blown in
the component recognition lighting unit.
(Cause 1) The lamp of the component recognition lighting device was burnt out.
(Remedy 1) Replace the lamp with a new one.
After the replacement, perform the teaching operation required for com-
ponent recognition.
