Software Version Description, Station Software Version 407.05 07/2008 Edition
Requirements for machine types SIPLACE S20 and SIPLACE F
4
:
• Configuration level of M44 9
• MVS 200 EPROM = 2272E, GAL and Quarz XC75-6/A
• SW version of axes 1.81
• Coplanarity module COV 201.012f / 3.0ff, FW version = 308
• SW version C5 head EPROM 2.7 (item no. 00334205-07)
• SW version sub-modular head card 6.09
• SW version component table 5.02
Requirements for machine type SIPLACE F
5
:
• Configuration level of M44 9
• MVS 340 VME item no. 00335673-03, SW version = 2321M
• SW version of axes 1.81
• Coplanarity module COV 201.012f / 3.0ff, FW version = 308
• SW version C5 head EPROM 2.7 (item no. 00334205-07)
• SW version sub-modular head card 6.09
• SW version component table 5.02
Requirements for machine type SIPLACE S23:
• Configuration level of M54 2
• MVS 340 VME item no. 00335673-03, SW version = 2321M
• SW version of axes 4.03
• Servo configuration level 2 for X-axis, Y-axis and star axis
• Servo TDS120/A2.5Z für Z-axis
• SW version C5 head EPROM 2.7 (item no. 00334205-07) or
• SW version modular head card 6.09
• SW version component table 5.02
Requirements for machine type SIPLACE F5HM:
• Configuration level of M54 2
• MVS 340 VME item no. 00335673-03, SW version = 2321M
• SW version of axes 4.03
• Coplanarity module COV 201.012f / 3.0ff, FW version = 308
• Servo configuration level 2 for X-axis, Y-axis and star axis
• SW version modular head card 6.09
• SW version component table 5.02
12 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
CAUTION !
Following the exchange of GAL and Quartz on the
MVS, the entire machine has to be measured!
For the calibration of the machine, the calibration tool
pocket with integrated machine zero point has to be
installed!
The V24 link from the machine controller to the station
computer needs to be disconnected on both sides if
the predecessor software version used at the machine
is of an earlier release than 404.01.
On no account should the machine be switched off
during the download of the ICOS software to the MVS.
13 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
5 New Functions
5.1 New Functions in 407.05
Software version 407.05 is based on Version 407.04 SP2 and comprises all the functions and error
corrections for this version.
The corrected defects are described in chapter 6.
5.1.1 Revision of the Forced Setup Verification
The forced setup verification at the SIPLACE placement machine can be activated via SIPLACE Setup
Center. The forced setup verification monitors the verification status of individual tracks. Non-verified tracks
are disabled to force setup verification.
Forced setup verification is carried out with a connection to the station and requires successful setup
verification before production. This is implemented as follows: once an order or a packaging unit changeover
has been downloaded, the machine deactivates all divisions in which there are packaging units for which no
setup verification data has been received.
This means the line operator needs to successfully verify all the necessary components/packaging units for
the product before production can begin.
A detailed description can be found in the "Installation Manual SIPLACE Setup Center 3.0", item no.
00195642-xx.
Requirements
The forced setup verification requires SIPLACE Pro as of Version 5.0 and SIPLACE Setup Center as of
Version 3.0.
If Splice sensors are used, SIPLACE Pro as of Version 5.2 and SIPLACE Setup Center as of Version 3.0 are
required. Withour Splice sensors SIPLACE Pro as of Version 3.2 and Setup Center as of Version 3.0 are
required.
5.2 New Functions in 407.04 SP2
Software version 407.04 SP2 is based on Version 407.04 SP1 C and comprises all the functions and error
corrections for this version (and includes also the patch "Mobilink").
There are no further new functions in this version.
The corrected defects are described in chapter 6.
14 of 104
