Software Version Description, Station Software Version 407.05 07/2008 Edition
5.7.6 Revision of the User Interface and Improved Fiducial and Ink Spot
Recognition
A new fiducial recognition system (synthetic fiducials) and a new ink spot recognition system (fast ink spots)
have been implemented in version 407.01. To further improve the handling of these new processes, the user
interface for the manipulators for the creation of models for and testing of synthetic fiducials and fast ink
spots has been revised in version 407.02. However, the functionality behind the graphical user interface
remains largely the same. There are only two differences worth mentioning: Firstly, the model type (synthetic
fiducial, fast ink spot or 2D fiducial) now has to be specified when a new descriptive model is created.
Secondly, the search area for synthetic fiducials is now defined by a square, the edge length of which is
obtained from the model dimensions plus the size tolerances plus the artwork tolerances. It thus describes
that part of the camera image used by the analysis system for the purpose of fiducial recognition. Up to now,
only the artwork tolerance had to be specified here.
29 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
5.7.7 Changes to the Machine Data
5.7.7.1 Machine Data Converter
The machine data converter makes changes to the following machine files at level 75:
SIPLACE F
4
/ F
5
File Variable Description / Restriction
Konfig_L.ma Sensor system IDs/gantry group 0 Change for gantry group 1 (00723)
Coplanarity module removed
Konfig_r.ma Sensor system IDs/gantry group 0 Change for gantry group 1 (00723)
Coplanarity module removed
Kraft_12.ma Axis block 1:
In addition, 1 active value ID: 19
All force levels: 6th value, old 2047, new 80
Force level 13 (higher than 8x noz.): 2nd value, old 80, new 40
Force level 13 (higher than 8x noz.): 3rd value, old 18, new 0
Force level 13 (higher than 8x noz.): 4th and 5th value, old 250,
new 150
Force level 13 (higher than 8x noz.): 6th value, old 2047, new
20
Changed values for pick-up with
nozzles in 8-nozzle heads
PPW_STD.MA \ D-Sollposition \ jeweils 0 Nozzles wiped off at 0 degrees (00601)
REAL.MA Backlash time Backlash times changed (00603)
SCANPA06.MA New parameter values (00614)
SCANPA12.MA New parameter values (00614)
TRANSP.MA Center conveyor coasting and PCB
timeout configurable (00604)
ref_lauf.ma Default entry for adjustable retries for
the error: track empty (00605)
30 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
SIPLACE F5HM
File Variable Description / Restriction
KONFIG_L.MA Sensor system IDs/gantry group 0 Change to gantry group 1 (00723)
Coplanarity removed
KONFIG_R.MA Sensor system IDs/gantry group 0 Change to gantry group 1 (00723)
Coplanarity removed
PPW_STD.MA \ D-Sollposition \ jeweils 0 Nozzles wiped off at 0 degrees (00601)
SCANPA06.MA New parameter values (00614)
SCANPA12.MA New parameter values (00614)
TRANSP.MA Center conveyor coasting and PCB
timeout configurable (00604)
ref_lauf.ma Default entry for SpurleerMax (605)
scanpafc.ma New parameter values (00614)
