Software Version Description, Station Software Version 407.05 07/2008 Edition
5.8.13 fk_off.ma - Correction File for Fine Calibration
The correction values derived from the machine capability analysis and fine calibration used to be held in
real.ma. They have now been transferred to the file fk_off.ma. The entries for the relevant camera IDs and
transports are located in the file. The mean offsets from the machine capability analysis must be added to
the values in the "Global" data record depending on the feeder. (Important: These used to be subtracted in
real.ma!) The angle-dependent correction values from wnk_korr.ma (this file is removed) have also been
moved to the new file fk_off.ma. . The relevant offsets for the angles from fine calibration during the
assembly with IC head are added to the values in the records "0", "90", "180", "270", depending on the
conveyor.
Example:
\Dataset 1. BE-Camera \
\ CameraID \ 12#
\ KameraTyp \ "C&P12"#
\ Level \ 1#
\ Number of sets \ 1#
\ 1. Correction Set \
\ ID-Name \ "GLOBAL";
\ 1. Transport \
\X-Offset in microns \ 8,
\Y-Offset in microns \ -9,
\W-Offset in 1/100 degree \ 1!
Adding the global
offsets
depending on
the conveyor in which
the measuring plate
was placed.
\ 2. Transport \
\X-Offset in microns \ -7,
\Y-Offset in microns \ 13,
\W-Offset in 1/100 degree \ -2!
5.8.14 Improvements in the SITEST Test and Commissioning Program
5.8.14.1 Illumination Values for Live Images in SITEST
The illumination values for various illumination levels can be set for the new "Multicolor" PCB camera for the
live image, in order to test the illumination.
This button is inactive for the old PCB camera!
5.8.14.2 Accelerated calibration of the 12-segment C&P head
Measurement of segment offset I and segment offset II is now only repeated 4x for 12-segment heads.
For reasons of accuracy, the measurement is repeated 8x for 6-segment heads.
37 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
5.8.14.3 Rapid head mapping
C&P and IC head mapping is now carried out with only one calibration tool package form instead of 4.
For this reason, the calibration tool package form is picked up off center.
5.8.15 Changes to the Machine Data
5.8.15.1 Machine Data Converter
The machine data converter makes changes to the following machine files at level 70:
File Variable Description / Restriction
Height offsets Read global offset values and make entry in FK_OFF.MA
Then reset Height Offsets to zero.
REAL.MA
Backlash time Set backlash time of the C&P camera to 50 ms
Restriction: only 6-nozzle heads with standard or DCA
cameras.
WNK_KORR.MA
Angle correction values Read correction values and make entry in FK_OFF.MA
WNK_KORR.MA is then deleted by the installation procedure.
Vacuum threshold, pickup/place Set to 30% for all heads.
VAKUUM.MA
Number of errors per segment Set number of errors per segment from 3 to 10.
Restriction: For 12-nozzle heads only
FK_OFF.MA
New file Values from REAL.MA are transferred in inverted form.
Correction values from WNK_KORR.MA are transferred.
TRANSP.MA
Input conveyor sensor timeout Introduce input conveyor sensor timeout [s] for both conveyor
tracks and set to 8 s.
The following values are changed during installation of the MC software.
File Variable Description / Restriction
KALI_GF.*
KALI_MB.*
Files from the directory D:\Dat (MC) are used from C:\
SRDaten \ SrcSiTest .. (SC) as of Version 407.
VAK_Z.MA
Nozzle type 902 added
VAKUUM.MA
Evaluation of minimum vacuum
distance
Changed data format
ACHS12MF.MA
ACHS12OF.MA
ACHS6MF.MA
ACHS6OF.MA
AX12STD.MA
AX6STD.MA
Values for forces, acceleration and positions changed.
38 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
6 Error Corrections
6.1 Errors Corrected in the 407.05 Software
1-9MYGD
On an F5HM machine an error concerning the segments 2-5 often occurred for the 6 nozzle head
(segment untight after placement). The software for the axes has been adapted
1-DTQP0
The reference run of the C&P head did not work, because some segments were empty. Empty
segments will not be regarded during heights reference run anymore.
1-CO0XG
During placement of a high component from a tray (last component of the PCB) a track error occurred,
but the level did not turn back into the tower as the PCB was finished.
If a component then was picked up from a tray for the next PCB, the level with the high component was
still activated, since the SP head was reactivated when a track or a tray was filled up with components.
This reactivation is not performed by filling up anymore.
1-COMI5
After placing high components on an F
4
machine, an empty segment of the 12-nozzle head was not
moved down during parking. The function has been adapted.
1-GE58V
OIS did not document component rejects correctly, since an error message was not forwarded to OIS.
The error log file has been adapted accordingly.
1-GEXBA
By rebooting a SIPLACE S20 machine, the error message "konfig.ma file missing or faulty" was
displayed. This was caused by timing problems during access on the konfig.ma file. The access method
has been modified.
752-4SF
On an F
5
machine, the entries for 2 feeder tracks were missing in the Component Level Indicator (CLI)
on the station GUI. The error has been corrected.
D1-34579101
It was impossible to activate a reel and BCSupplier.exe registered a problem. The error has been
corrected.
D1-34855617
Conveyor error as PCB was transferred between an HS50 and an F4 machine. The error has been
corrected.
