Software Version Description, Station Software Version 407.05 07/2008 Edition
9.2 Installation of the Machine Controller Operating System
9.2.1 SIPLACE S20, SIPLACE F4 and SIPLACE F5
9.2.1.1 Configuration of the M44 BIOS
The automatic detection function must not be used for the hard disk settings in Setup. The following
parameters must be entered manually.
CYLS: HEADS: Sectors: ...
Disk 0: 49 (202MB) 989 12 35 ...
9.2.1.2 Installation
• Insert the "MC RMOS 80S/F, BOOT DISK Disk -1/2-" diskette into the floppy disk drive of the M44 and
turn on the station.
Copies of the diskettes are also contained on the CD of the station software in the directory Siplace \Sip_mc
\ <machine type>\FD_image.RM3. The diskettes for the machine controller operating system can be created
on any PC with Windows-NT, e.g. station computers. To this end, start the programs rmos-1.exe, or
rmos-2.exe and follow the directions.
The following message is displayed on the screen:
PLEASE CHECK IF THE FOLLOWING SYSTEM MESSAGE IS DISPLAYED ABOVE THIS TEXT:
IF NO SUCH MESSAGE IS DISPLAYED:
- REBOOT SYSTEM AND ENTER 'SETUP MENUE'
- CHANGE STATUS OF VIRUS WARNINMG TO 'DISABLED'
ELSE CONTINUE INSTALLATION ...
[Y] SETUP CORRECT, CONTINUE [N] REBOOT SYSTEM TO CHANGE SETUP
[A] SET INTERNET ADDRESS
PRESS KEY TO CONTINUE [Y,N,A]?
VIRUS WARNING IS SET DISABLED !
NO WARNING IF BOOT SECTOR IS TO BE MODIFIED
Starting MS-DOS...
VIRUS WARNING IS SET DISABLED !
NO WARNING IF BOOT SECTOR IS TO BE MODIFIED
If "A" is chosen, the setting of the network addresses and port IDs can be performed at this point (see
section
9.2.1.3).
If the screen display is the same as shown above, continue the installation by choosing "Y".
61 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
Warning !
If the virus warnings are not DISABLED!, the machine must be rebooted by typing "N".
Note
Following the initial installation it is necessary that the standard files installed be adapted to the user
network.
In the case of updates / upgrades, the already-set network addresses will be retained.
The Internet addresses of the M44 are stored in "C:\ETC\HOSTS".
The port IDs of the M44 are stored in "C:\ETC\SERVICES".
• Press any key to continue, press <Esc> to abort the installation.
• The software version and the machine type are displayed.
• Press any key to continue, press <Esc> to abort the installation.
62 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
• The main menu is displayed.
>>>
>>>
------------------
Install Revision of RMOS Operating System
------------------
Terminate RMOS Installation Program
Main Menue of RMOS Installation
Use the [Up Arrow] [Down Arrow] [Pg Up] [Pg Dn] keys to move the highlight bar to select the
button you prefer.
Press [Enter] to activate your selection
Note
If a submenu or a function is selected in the installation program, the cursor will be flashing in gray.
• Select the "Install Revision of RMOS Operating System" function and confirm with <RETURN>.
• Installation is started, the following query is displayed:
>>>
>>>
-----No
-----Yes
1. WARNING
installation of RMOS operating system will only save files keeping machine data.
A
ll other files of user’s interrest have to be saved on floppy disc by user manually.
Otherwise these files will bedeleted.
Continue RMOS Installation Job?
Use the [Up Arrow] [Down Arrow] [Pg Up] [Pg Dn] keys to move the highlight bar to select the
button you prefer.
Press [Enter] to activate your selection
• Use the cursor keys to select whether you wish to continue ("Yes") with the installation or to abort ("No").
WARNING!
Only the Machine Data will be saved. All user data will be deleted. Save your user data to diskettes, if
necessary.
