Software Version Description, Station Software Version 407.05 07/2008 Edition • The main menu is displayed. >>> >>> ------------------ Install Revision of RM OS Operat ing System ------------------ Term…
Software Version Description, Station Software Version 407.05 07/2008 Edition
Warning !
If the virus warnings are not DISABLED!, the machine must be rebooted by typing "N".
Note
Following the initial installation it is necessary that the standard files installed be adapted to the user
network.
In the case of updates / upgrades, the already-set network addresses will be retained.
The Internet addresses of the M44 are stored in "C:\ETC\HOSTS".
The port IDs of the M44 are stored in "C:\ETC\SERVICES".
• Press any key to continue, press <Esc> to abort the installation.
• The software version and the machine type are displayed.
• Press any key to continue, press <Esc> to abort the installation.
62 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
• The main menu is displayed.
>>>
>>>
------------------
Install Revision of RMOS Operating System
------------------
Terminate RMOS Installation Program
Main Menue of RMOS Installation
Use the [Up Arrow] [Down Arrow] [Pg Up] [Pg Dn] keys to move the highlight bar to select the
button you prefer.
Press [Enter] to activate your selection
Note
If a submenu or a function is selected in the installation program, the cursor will be flashing in gray.
• Select the "Install Revision of RMOS Operating System" function and confirm with <RETURN>.
• Installation is started, the following query is displayed:
>>>
>>>
-----No
-----Yes
1. WARNING
installation of RMOS operating system will only save files keeping machine data.
A
ll other files of user’s interrest have to be saved on floppy disc by user manually.
Otherwise these files will bedeleted.
Continue RMOS Installation Job?
Use the [Up Arrow] [Down Arrow] [Pg Up] [Pg Dn] keys to move the highlight bar to select the
button you prefer.
Press [Enter] to activate your selection
• Use the cursor keys to select whether you wish to continue ("Yes") with the installation or to abort ("No").
WARNING!
Only the Machine Data will be saved. All user data will be deleted. Save your user data to diskettes, if
necessary.
63 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
• Confirm your selection with <RETURN>.
• If you have selected "Yes", the installation will be continued, and the following display will appear on the
screen.
>>>
>>>
-----No
-----Yes
2. WARNING
Drive ´C:´ of your hard disc will be formatted:
=> all files will be deleted.
Continue RMOS Installation Job?
Use the [Up Arrow] [Down Arrow] [Pg Up] [Pg Dn] keys to move the highlight bar to select the
button you prefer.
Press [Enter] to activate your selection
• Use the cursor keys to select whether you wish to continue with the installation or to abort.
WARNING!
Partition C: will be formatted. All data will now be deleted.
• Confirm your choice by pressing the <RETURN> key, the installation is continued.
• You will now be prompted to insert the diskette MCRMOS 80S/80F Disk -1/2- into the floppy disk drive.
• Once both diskettes have been installed, the message "Installation finished" is displayed.
The installation of the M44 operating system has thus been completed.
Now remove the diskette from the disk drive and turn the machine off and back on again.
64 of 104
