Software Version Description, Station Software Version 407.05 07/2008 Edition

9.2.1.3 Changing Network Addresses

To change the Internet addresses, proceed as follows:

• Switch the machine off.

• Insert installation diskette #1 and switch the machine on.

• When the first menu appears, press key "A".

• The menu selection box for setting the Internet addresses or port IDs appears.

[X] EXIT M ENU [H] SET INTERN ET ADDRESS

[S] SET PO RT ID

PRESS KEY TO CO NTINUE [H,S,X]?

• If "H" is selected, the "\ETC\HOSTS" file will be displayed in the DOS editor.

The Internet addresses and system names valid for this station are to be entered.

Note:

On no account may ALIAS names such as "autlr", "autsr" and "localhost" be changed,

as these names are used and required by the software.

• PL EA 1 have a worldwide unique class B Internet address. This official class B Internet address is

139.10 (.x.y). Within this address range all SIPLACE LAN communications partners are operated. We

will make the correct settings for you. If you have any queries, please contact our Service dept.

9.2.1.4 Troubleshooting

In the event of the installation program being terminated prematurely, on account of a fault:

• remove the diskette from the disk drive and turn off the machine.

• Insert diskette #1 in the disk drive and turn the machine back on.

• Try to repeat the station software installation.

NOTE

If the second attempt at installing the software is also unsuccessful, please contact the Service

department in charge.

65 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

9.2.2 SIPLACE S23 and SIPLACE F5HM

9.2.2.1 Configuration of M54-BIOS

For the M54 of the SIPLACE S23 and SIPLACE F5HM, the correct BIOS settings have to be made prior to

the initial installation of the operating system. The same applies in the case of data loss in CMOS-RAM.

The settings can be made either manually or by means of the configuration program supplied.

9.2.2.1.1 BIOS Configuration Program

The settings in the BIOS of the M54 can be carried out by means of the supplied configuration program. To

this end, place the diskette with the configuration program in the disk drive of the machine controller and turn

on the machine. Similar to the manual configuration, call up the Setup of BIOS and check the following

settings:

• Floppy Disk/Drive A: 1.44MByte

• Boot Features/Boot Sequence: A:, C:

Exit from the BIOS Setup and save the changes. Subsequently, the configuration program is started up.

When the DOS prompts A:\ appears, the configuration is finished.

A copy of the diskette is also contained on the station software CD in the directory

sip_mc\80S23\FD_image.RM3. The diskette can be created on any PC running under Windows-NT, e.g. the

station computer. To this end, start mcbios.exe and follow the directions.

With this kind of configuration, the values are held in the flash ROM of the BIOS so that in the event of a data

loss in the CMOS-RAM of the BIOS the correct values are set as default.

66 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

9.2.2.1.2 Manual Configuration of the M54 BIOS

To start the BIOS Setup, wait after the system start until the following message displays on the screen. Then

actuate the <F2> key.

PowerBIOS Version 1.00

12/06/96 - Intel - 82430HX

AMS-M54 V 1.00

+------------------------------------------------------------------------+

¦ CPU Type...............................................Pentium xxx MHz ¦

¦ Math CoProcessor..............................................Internal ¦

¦ . ¦

+------------------------------------------------------------------------+

Press F2 to enter setup

Main Menu

Setup displays the following entry menu:

+------------------------------------+

¦ Award Software International, Inc. ¦

¦ PowerBIOS 1.00 Setup ¦

¦ +------------------+ ¦

¦ ¦ System Security ¦ ¦

¦ ¦ Date and Time ¦ +------+ ¦

¦ ¦ AT Hard Disk ¦ ¦ OPEN ¦ ¦

¦ ¦ Floppy Disk ¦ +------+ ¦

¦ ¦ Boot Features ¦ ¦

¦ ¦ Standard Chipset ¦ +------+ ¦

¦ ¦ Advanced Chipset ¦ ¦Cancel¦ ¦

¦ ¦ Peripherals ¦ +------+ ¦

¦ ¦ PCI Setup ¦ ¦

¦ ¦ IMC Interrupts ¦ ¦

¦ ¦ COM Redirection ¦ ¦

¦ ¦ IMC Miscellaneous¦ ¦

¦ ¦ ¦ ¦

¦ +------------------+ ¦

¦ Press [F4] key to toggle color ¦

¦ Press [F1] key for help ¦

+------------------------------------+
