Software Version Description, Station Software Version 407.05 07/2008 Edition

 Setup page "Boot Features"

+----------------------¦ Boot Features +-----------------------+

¦ ¦

¦ +------+ +------+ +-------+ ¦

¦ Press [F1] key for help ¦ OK ¦ ¦Cancel¦ ¦Default¦ ¦

¦ +------+ +------+ +-------+ ¦

¦ +-Boot Sequence---------+ +-Keyboard State-----------------+ ¦

¦ ¦ ¦ ¦ [ ] Typematic Settings Enabled ¦ ¦

¦ ¦ (*) A:, C: ¦ ¦ Typematic Rate: 6 (char/s) ¦ ¦

¦ ¦ ( ) C:, A: ¦ ¦ Typematic Delay: 250 (msec) ¦ ¦

¦ ¦ ¦ ¦ [v] Num Lock On ¦ ¦

¦ +-----------------------+ +--------------------------------+ ¦

¦ +-Halt On Errors--------+ +-System Memory------------------+ ¦

¦ ¦ [v] Halt on Errors ¦ ¦ ¦ ¦

¦ ¦ Except for ... ¦ ¦ [ ] Quick Memory Test ¦ ¦

¦ ¦ [ ] Keyboard Errors ¦ ¦ ¦ ¦

¦ ¦ [ ] Disk Errors ¦ ¦ ¦ ¦

¦ +-----------------------+ +--------------------------------+ ¦

¦ Press [F1] key for help ¦

+--------------------------------------------------------------+

 Setup page "Standard Chipset"

+--------------------¦ Standard Chipset +---------------------+

¦ ¦

¦ +------+ +------+ +-------+ ¦

¦ ¦ OK ¦ ¦Cancel¦ ¦Default¦ ¦

¦ +-System Cache-------------+ +------+ +------+ +-------+ ¦

¦ ¦ ( ) Disabled ¦ ¦

¦ ¦ ( ) Primary Only ¦ +-Secondary Cache Size-------+ ¦

¦ ¦ (*) Primary and Secondary¦ ¦ 256 KB Pipelined Burst ¦ ¦

¦ +--------------------------+ +----------------------------+ ¦

¦ +-Shadow and Cache Options--------------------------------+ ¦

¦ ¦ Shadow Cache Shadow Cache ¦ ¦

¦ ¦ System ROM: [v] Video ROM: [v] [v] ¦ ¦

¦ ¦ C800-CBFF: [ ] [ ] CC00-CFFF: [ ] [ ] ¦ ¦

¦ ¦ D000-D3FF: [ ] [ ] D400-D7FF: [ ] [ ] ¦ ¦

¦ ¦ D800-DBFF: [ ] [ ] DC00-DFFF: [ ] [ ] ¦ ¦

¦ +---------------------------------------------------------+ ¦

¦ Press [F1] key for help ¦

+-------------------------------------------------------------+

71 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

 Setup page "Advanced Chipset"

+---------------------------¦ Advanced Chipset +----------------------------+

¦+-DRAM Timing-----------------------++-DRAM Error--------++--------------+ ¦

¦¦ ¦¦ ¦¦ +------+ ¦ ¦

¦¦ DRAM Speed: (*) 60 ns ¦¦ ¦¦ ¦ OK ¦ ¦ ¦

¦¦ ( ) 70 ns ¦¦ (*) None ¦¦ +------+ ¦ ¦

¦¦ ( ) User defined ¦¦ ( ) Parity ¦¦ +------+ ¦ ¦

¦¦ ¦¦ ( ) ECC ¦¦ ¦Cancel¦ ¦ ¦

¦¦ DRAM Read Burst: x222/x333 ¦¦ ¦¦ +------+ ¦ ¦

¦¦ DRAM Write Burst: x222 ¦¦ (*) Multiple ¦¦ ¦ ¦

¦¦ Fast RAS to CAS Delay: 3 Clocks ¦¦ ( ) Single ¦¦ +-------+ ¦ ¦

¦¦ Leadoff: 6 Cl-Rd, 5 Cl-Wr, 3 RAS ¦¦ ¦¦ ¦Default¦ ¦ ¦

¦¦ ¦¦ ¦¦ +-------+ ¦ ¦

¦+-----------------------------------++-------------------++--------------+ ¦

¦+-I/O Recovery Times----------------++-Miscellaneous---------------------+ ¦

¦¦ ¦¦ ¦ ¦

¦¦ 8 Bit Cycles: +1 Clock ¦¦ [v] Enable Memory Hole at 15-16MB ¦ ¦

¦¦ 16 Bit Cycles: +1 Clock ¦¦ ¦ ¦

¦¦ ¦¦ ¦ ¦

¦+-----------------------------------++-----------------------------------+ ¦

¦ Press [F1] key for help ¦

+---------------------------------------------------------------------------+

Miscellaneous

Enable Memory Hole

at 15-16MB

Address window for SIPLACE GEM option

 Setup page "Peripherals"

+------------------------¦ Peripherals +------------------------+

¦ ¦

¦ +-Serial / Parallel Ports-----------------------+ ¦

¦ ¦ Serial Port A: 3F8h, IRQ4 ¦ +------+ ¦

¦ ¦ Serial Port B: 2F8h, IRQ3 ¦ ¦ OK ¦ ¦

¦ ¦ Parallel Port: 378h, IRQ7 Bidirectional ¦ +------+ ¦

¦ +-----------------------------------------------+ ¦

¦ +-IDE / Floppy Controller-----------------------+ +------+ ¦

¦ ¦ Primary IDE: Enabled ¦ ¦Cancel¦ ¦

¦ ¦ Secondary IDE: Disabled ¦ +------+ ¦

¦ ¦ Floppy Disks: Enabled Normal ¦ ¦

¦ +-----------------------------------------------+ +-------+ ¦

¦ +-Miscellaneous---------------------------------+ ¦Default¦ ¦

¦ ¦ PS/2 Mouse: Enabled ¦ +-------+ ¦

¦ +-----------------------------------------------+ ¦

¦ Press [F1] key for help ¦

+---------------------------------------------------------------+

72 of 104

Software Version Description, Station Software Version 407.05 07/2008 Edition

 Setup page "PCI Setup"

+----------------¦ PCI Setup +---------------+

¦ +--------------------------+ ¦

¦ ¦ MultiMedia Enable: [ ] ¦ +------+ ¦

¦ +--------------------------+ ¦ OK ¦ ¦

¦ +--------------------------+ +------+ ¦

¦ ¦ PCI INT IRQ ¦ +------+ ¦

¦ ¦ A: 7 ¦ ¦Cancel¦ ¦

¦ ¦ B: NONE ¦ +------+ ¦

¦ ¦ C: NONE ¦ +-------+ ¦

¦ ¦ D: NONE ¦ ¦Default¦ ¦

¦ +--------------------------+ +-------+ ¦

¦ Press [F1] key for help ¦

+--------------------------------------------+

PCI-Interrupt-Routing

For each PCI INT (= motherboard INT) an IRQ can now be defined in the setup fields.

Since the LAN card of the M54 module is designed as a PCI card, PCI INT A is required.

In Setup, IRQ 7 is to be entered for PCI INT A. During start-up, BIOS will then assign this IRQ to the PCI

card.

 Setup page "IMC Interrupts"

+---------------------¦ IMC Interrupts +------------------------+

¦ ¦

¦ +-----------------------------------------------+ +------+ ¦

¦ ¦ PC-IRQ IRQ-Source IRQ-Mode ¦ ¦ OK ¦ ¦

¦ ¦ 3 onboard COM transparent ¦ +------+ ¦

¦ ¦ 4 onboard COM transparent ¦ +------+ ¦

¦ ¦ 5 MISC_INT transparent ¦ ¦CANCEL¦ ¦

¦ ¦ 6 onboard Floppy transparent ¦ +------+ ¦

¦ ¦ 7 not assigned transparent ¦ +-------+ ¦

¦ ¦ 10 SMP_INT5 transparent ¦ ¦Default¦ ¦

¦ ¦ 11 SMP_INT6 transparent ¦ +-------+ ¦

¦ ¦ 14 onboard IDE transparent ¦ ¦

¦ +-----------------------------------------------+ ¦

¦ ¦

¦ Press [F1] key for help ¦

+---------------------------------------------------------------+

This setup page is used to set the electronic interrupt matrix.
