Software Version Description, Station Software Version 407.05 07/2008 Edition
Setup page "PCI Setup"
+----------------¦ PCI Setup +---------------+
¦ +--------------------------+ ¦
¦ ¦ MultiMedia Enable: [ ] ¦ +------+ ¦
¦ +--------------------------+ ¦ OK ¦ ¦
¦ +--------------------------+ +------+ ¦
¦ ¦ PCI INT IRQ ¦ +------+ ¦
¦ ¦ A: 7 ¦ ¦Cancel¦ ¦
¦ ¦ B: NONE ¦ +------+ ¦
¦ ¦ C: NONE ¦ +-------+ ¦
¦ ¦ D: NONE ¦ ¦Default¦ ¦
¦ +--------------------------+ +-------+ ¦
¦ Press [F1] key for help ¦
+--------------------------------------------+
PCI-Interrupt-Routing
For each PCI INT (= motherboard INT) an IRQ can now be defined in the setup fields.
Since the LAN card of the M54 module is designed as a PCI card, PCI INT A is required.
In Setup, IRQ 7 is to be entered for PCI INT A. During start-up, BIOS will then assign this IRQ to the PCI
card.
Setup page "IMC Interrupts"
+---------------------¦ IMC Interrupts +------------------------+
¦ ¦
¦ +-----------------------------------------------+ +------+ ¦
¦ ¦ PC-IRQ IRQ-Source IRQ-Mode ¦ ¦ OK ¦ ¦
¦ ¦ 3 onboard COM transparent ¦ +------+ ¦
¦ ¦ 4 onboard COM transparent ¦ +------+ ¦
¦ ¦ 5 MISC_INT transparent ¦ ¦CANCEL¦ ¦
¦ ¦ 6 onboard Floppy transparent ¦ +------+ ¦
¦ ¦ 7 not assigned transparent ¦ +-------+ ¦
¦ ¦ 10 SMP_INT5 transparent ¦ ¦Default¦ ¦
¦ ¦ 11 SMP_INT6 transparent ¦ +-------+ ¦
¦ ¦ 14 onboard IDE transparent ¦ ¦
¦ +-----------------------------------------------+ ¦
¦ ¦
¦ ¦
¦ Press [F1] key for help ¦
+---------------------------------------------------------------+
This setup page is used to set the electronic interrupt matrix.
73 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
Setup page "COM Redirection"
+---------¦ COM Redirection +-----------+
¦ ¦
¦ +-Status-------------------+ +------+ ¦
¦ ¦ ( ) disabled ¦ ¦ OK ¦ ¦
¦ ¦ (*) enabled ¦ +------+ ¦
¦ ¦ ( ) enabled (ANSI/VT100) ¦ +------+ ¦
¦ +--------------------------+ ¦Cancel¦ ¦
¦ +-Baudrate-----------------+ +------+ ¦
¦ ¦ ( ) 9600 Bd ¦ ¦
¦ ¦ (*) 19200 Bd ¦ ¦
¦ ¦ ( ) 38400 Bd ¦ ¦
¦ +--------------------------+ ¦
¦ +-Mode------------------------------+ ¦
¦ ¦ (*) Autoredirection ¦ ¦
¦ ¦ ( ) Redirect on Request only ¦ ¦
¦ +-----------------------------------+ ¦
¦ Press [F1] key for help ¦
+---------------------------------------+
Setup page "IMC Miscellaneous"
+-----------------¦ IMC Miscellaneous +----------------+
¦ ¦
¦ +-Keyboard-------------------------------+ +------+ ¦
¦ ¦[ ] Disable CTRL-C/CTRL-BREAK ¦ ¦ OK ¦ ¦
¦ ¦[ ] Force Cold boot on CTRL-ALT-DEL ¦ +------+ ¦
¦ +----------------------------------------+ +------+ ¦
¦ +-BIOS-E-Segment-------------------------+ ¦Cancel¦ ¦
¦ ¦[v] Disable BIOS E-Segment at boot ¦ +------+ ¦
¦ +----------------------------------------+ ¦
¦ ¦
¦ Press [F1] key for help ¦
+------------------------------------------------------+
BIOS-E-Segment
Disable BIOS
E-Segment at boot
If this option is activated, the E-segment of the BIOS will be deactivated prior
to booting. Any access in this area will be passed on to the PCI bus and thus
to the ISA or SMP16 bus.
(Interface to axis controller boards)
74 of 104
Software Version Description, Station Software Version 407.05 07/2008 Edition
Setup settings
Setup Page Parameter Value
System Security Enter Setup -
System Boot -
Floppy Disk Read Only disabled
Hard Disk Read Only disabled
Date and Time Date
current date
Time
current time
AT Hard Disk Hard Disk Type A
see illustration
Hard Disk Type B -
Hard Disk Type C -
Hard Disk Type D -
Block Mode
disabled
32-Bit Mode
disabled
Fast PIO
disabled
Floppy Disk Drive A: 1,44 MByte
Drive B: none
Test Floppy Disks enabled
Boot Features Boot Sequence A:, C:
Quick Memory Test disabled
Halt on Errors disabled
Keyboard Errors disabled
Disk Errors disabled
Num Lock On enabled
Standard Chipset System Cache primary and secondary
System ROM Cache
Video ROM Shadow, Cache
Other disabled
Advanced Chipset DRAM Timing 60 ns
16-Bit I/O Recovery 1 Clock
8-Bit I/O Recovery 1 Clock
Parity Check disabled
Memory Hole
enabled
Peripherals Serial Port A 3F8h, IRQ4
Serial Port B 2F8h, IRQ3
Parallel Port 378h, IRQ7, bidirectional
Primary DIE enabled
Secondary DIE disabled
Floppy Disks enabled, normal
PS/2 Mouse enabled
IMC Interrupts PC-IRQ
IRQ-Source IRQ-Mode
3 Onboard COM transparent
4 Onboard COM transparent
5
MISC_INT
transparent
6 Onboard Floppy transparent
75 of 104
