Pos. Item no. Description Part marking
03106559-01 CONFIG JTF X-SERIES S (REMAINS
110)
00166651-01 TABLE LOC2 JEDEC TRAY FEEDER X-
SERIES S
RETROFIT KIT
3 03107462-01 JTF LOC2 X-SERIES S BASE ASSY
4 03103961S01 FIXED TABLE W/ JTF3 M2 SPARE PART
5 03108706-01 PROTECTION PLATE JTF3
6 03098212-01 COVER PLATE, CO INSERT, X CPL.
7 03098198-01 COVER PLATE, CO INSERT, X
8 03045201-01 DIN EN ISO 7380-M4 X 8-A2-70
9 03067460-01 WASTE SLIDE WELDED COMPLETE SPARE PART
10 03039243-01 EXTENSION SPARE PART
11 03009344-01 WARNING LABEL NO. 205
03041705-01 EDGE PROTECTION 115 MM LONG
00346434S01 EDGE PROTECTION TYPE 4610026
(HAPPICH)
CONSUMABLE
14 03089040-01 WARNING DECAL WASTE CHUTE
COT40
15 03022705-01 ISO 7093-1 - 3 - 200 HV - A2 STANDARD PARTS
16 03066690S02 TAPE CUTTER PNEUM. SIPLACE X-
SERIES
SPARE PART
17 03000489-06 MOUNTING PLATE FINISH PART
(SIPLACE HF)
SPARE PART
18 03000491-02 WIPER (TAPE CUTTER HF) SPARE PART
19 03019894-03 PROTECTIVE GUARD (SIPLACE HF) SPARE PART
20 03019896-03 BAFFLE PLATE (SIPLACE HF) SPARE PART
21 03000506-03 WIPER-CLIP LEFT (SIPLACE HF) SPARE PART
22 03000505-03 WIPER-CLIP RI (TAPE CUTTER HF) SPARE PART
23 03000518-03 HINGE (TAPE CUTTER HF) SPARE PART
24 03000493-02 CABLE TRAY (TAPE CUTTER HF)
03105139-01 WIRING DUCT 20X20X2000 -
HD-0.7L
26 03000553-02 MEASURER COVER (TAPE CUTTER
HF)
STANDARD PARTS
27 03000630-01 VALVE COMPL. (TAPE CUTTER HF)
00310744-01 SILENCER G-1/8 WEAR PART
29 03009259-03 MEASURER SET ALIGNET (TAPE
CUTTER HF)
SPARE PART
