31
OM-1683
1103-001
13.1 Outline of Maintenance
13.1.3 Items for Periodic Maintenance
The items (inspection, cleaning, lubrication, etc.) that require periodic
maintenance are classied and described based on each individual devices.
Reference
Refer to "13.2 Maintenance Check List" for the maintenance based on frequency
of use.
Notice
The * -marks represent that the items require maintenance only for the
rsttime.
Followthe○-markedmaintenancecycleforthesubsequentuse.
Table 5
Device Name
Inspection Cleaning,
and Lubricating Spots
Work
Maintenance Cycle
Daily Weekly Monthly
Every
3 Months
Every
6 Months
Yearly
13.3.2.1 PCB Positioning
Section
Upper Serface of Backup
Table
Cleaning
Ball Screw
Cleaning,
Lubrication
*
Ball Screw Splines
Cleaning,
Lubrication
13.3.2.2 Conveyor
Section
Linear Guide
Cleaning,
Lubrication
*
Support Pin Detection
Sensors
Cleaning,
Lubrication
PCB Detection Sensor
Cleaning
PEC Detection Fiber
Cleaning
PEC Detection Fiber
Mirror
Cleaning
32
OM-1683
1103-001
13.2 Maintenance Check List
13.2 Maintenance Check List
The periodic maintenance items (inspection, cleaning, lubrication, etc.) are
classied and described based on how frequently each item should be performed.
Use the tables below as check lists.
Reference
Refer to "13.3 Maintenance Spots" for the spots to be maintained.
13.2.1 Weekly Maintenance
Table 6
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
13.3.2.1 PCB
Positioning
Section
Upper Surface of Feeder
Base
Cleaning
----- Vacuum Cleaner
13.3.2.2 Conveyor
Section
Support Pin Detection
Sensors
Cleaning
----- Rag
PCB Detection Sensor,
PEC Detection Sensor
Fiber
PCB Detection Sensor
Mirror
Cleaning
----- Rag
13.2.2 Quarterly Maintenance
Grease Symbols
DE1 : DAPHNE EPONEX GREASE No. 1
Notice
Lubrication must be made on the *-marked items after initial month and
every 3 months for the subsequent use.
Table 7
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
13.3.2.1 PCB
Positioning
Section
* Ball Screw
Cleaning,
Lubrication
DE1 Rag
13.3.2.2 Conveyor
Section
* Linear Guide
Cleaning,
Lubrication
DE1 Hand Grease Gun
Type H
13.2.3 Half-Yearly Maintenance
Grease Symbols
DE1 : DAPHNE EPONEX GREASE No. 1
Table 8
Object Unit
Inspection, Cleaning,
and Lubricating Spots
Work Grease Required Tools Check
13.3.2.1 PCB
Positioning
Section
Ball Screw
Splines
Cleaning,
Lubrication
DE1 Oiled Rag,
Hand Grease Gun,
SPK-3C
33
OM-1683
1103-001
13.3 Maintenance Spots
13.3 Maintenance Spots
13.3.1 Whole View
Notice
Any operations with a cover(s) being removed are included.
After the maintenance work, be sure to attach the cover.
Feeder Cart Section
Air Source
Vacuum System
Front View of Machine
Fig. 29
Reference
Refer to "13.3.2" and the subsequent items for the detailed information on the
spots of each section to be maintained and how to maintain them.
