5-8 AJK-ML T-ID 2. Layout of Sensors and Loads Rack Base Section (FP-G200L) 0706-002 2.7 Rack Base Section (FP-G200L) -B0422,-B0424 -B0428,-B0430 -B0423,-B0425 -B0429,-B0431 -Y0532 -Y0534 -B0513 -B0426 -B0516 -B0432 Symb…
5-7
AJK-MLT-ID
2. Layout of Sensors and Loads Elevator Section (FP-G200L)
0706-002
2.6 Elevator Section (FP-G200L)
-B0427
-M02
-M03
-B0202
-B0512
-B0515
-B0421
Symbol Name
Symbol Name
-M02
Elevator (Lower) Driving Motor
-M03
Elevator (Upper) Driving Motor
-B0202
Elevator U/D Approach Check
-B0421
Lower Rack Shutter (Operator Side) Closing Check
-B0427
Upper Rack Shutter (Operator Side) Closing Check
-B0512
Magazine (Lower) Type Determination
-B0515
Magazine (Upper) Type Determination
5-8
AJK-MLT-ID
2. Layout of Sensors and Loads Rack Base Section (FP-G200L)
0706-002
2.7 Rack Base Section (FP-G200L)
-B0422,-B0424
-B0428,-B0430
-B0423,-B0425
-B0429,-B0431
-Y0532
-Y0534
-B0513
-B0426
-B0516
-B0432
Symbol Name
Symbol Name
-B0422
Traverse Side Rack Shutter (Lower) Opening Check 1
-B0423
Traverse Side Rack Shutter (Lower) Opening Check 2
-B0424 Traverse Side Rack Shutter (Lower) Closing Check 1
-B0425 Traverse Side Rack Shutter (Lower) Closing Check 2
-B0426 Magazine (Lower) Positioning Check
-B0428
Traverse Side Rack Shutter (Upper) Opening Check 1
-B0429
Traverse Side Rack Shutter (Upper) Opening Check 2
-B0430 Traverse Side Rack Shutter (Upper) Closing Check 1
-B0431 Traverse Side Rack Shutter (Upper) Closing Check 2
-B0432 Magazine (Upper) Positioning Check
-B0513
Magazine Stopper (Lower) Return Check
-B0516
Magazine Stopper (Upper) Return Check
-Y0532
Magazine (Lower) Rack Shutter Open/Close Valve
-Y0534
Magazine (Upper) Rack Shutter Open/Close Valve
(Lower Section)
(Upper Section)
5-9
AJK-MLT-ID
2. Layout of Sensors and Loads Traverse Section (FP-G200L)
0706-002
2.8 Traverse Section (FP-G200L)
-B0511
-B0101
-M01
-B0417
-B0102
-B0417
-B0418
-Y0530
-B0415,-B0416
-B0413,-B0414
-B0418
Symbol Name
Symbol Name
-M01 Traverse Driving Motor
-B0101 Traverse Limit (+)
-B0102 Traverse Limit (-)
-B0413 Pallet Chuck 1 Clamping Check
-B0414 Pallet Chuck 1 Unclamping Check
-B0415 Pallet Chuck 2 Clamping Check
-B0416 Pallet Chuck 2 Unclamping Check
-B0417 Pickup Error Detection Sensor A
-B0418 Pickup Error Detection Sensor B
-B0419 Pickup Error Detection Sensor C
-B0511 Pallet Detection
-Y0530 Pallet Chuck Cylinder Valve
(Light Receiving)
(Light Receiving)
(Light Emitting)
(Light Emitting)
-B0419
(Light Receiving)
-B0419
(Light Emitting)
