5-13 AJK-ML T-ID 0706-002 3.3 Main Body CPU2 BOX (FP-G200R) -U90 (Elevator and T raverse Control) 3. Parts Location Main Body CPU2 BOX (FP-G200R)
5-12
AJK-MLT-ID
0706-002
3.2 Electrically Equipped Section (FP-G200R)
VIEW A
-TR-U04
(ILB)
-TR-U05
(I/O)
-K201
-K202
-K301
-K302 -Q101
-Q201
-K101
-K102
-K001
-K002
A
3. Parts Location Electrically Equipped Section (FP-G200R)
5-13
AJK-MLT-ID
0706-002
3.3 Main Body CPU2 BOX (FP-G200R)
-U90
(Elevator and Traverse Control)
3. Parts Location Main Body CPU2 BOX (FP-G200R)
5-14
AJK-MLT-ID
0706-002
3. Parts Location Frame Section (FP-G200L)
3.4 Frame Section (FP-G200L)
-TR-U06
[Lower Component
Supply] Switch
-HO001
(Power Lamp)
-A03
(Upper Elevator)
-A02
(Lower Elevator)
-A01
(Traverse)
-S0521[-H0542]
[Upper Ready] Switch
-TR-U07
[Upper Component
Supply] Switch
-S0522[-H0543]
[Magazine Change]
Switch
-S0520[-H0541]
[Lower Ready]
Switch
