1-24 AJK-ML T-ID 0706-002 3.6 T ray Magnets 3.6 T ray Magnets W A R N I N G Do not bring the tray magnet close to the area where a pacemaker is implanted. Otherwise, the pacemaker may be inuencedbyelectromagneticimpu…
1-23
AJK-MLT-ID
0706-002
•
To check if the pallet is deformed or not
Put the pallet on a at surface and check if the upper surface of the pallet is
distorted or not by means of a scale, etc.
Scale
Scale
Pallet
Pallet
Distortion (Clearance)
Fig. A12 Checking for Deformation of Pallet
3.5 Pallets
1-24
AJK-MLT-ID
0706-002
3.6 Tray Magnets
3.6 Tray Magnets
WARNING
Do not bring the tray magnet close to the area where a
pacemaker is implanted. Otherwise, the pacemaker may be
inuencedbyelectromagneticimpulsesofthemagnet,causing
the wearer to faint, etc.
CAUTION
Do not bring a magnetic card or a watch close to the tray
magnets.
Otherwise, the data of the magnetic card might be cleared or
a watch, etc., may be damaged due to the strong magnetism.
•
Mass and Size of
Tray Supportable by
Tray Magnet
Mass :
Approx. 400 g
Size :
Max. 315 mm
Max. 315 mm
Tray
Tray Magnets
Fig. A13 Tray Magnets
1-25
AJK-MLT-ID
0706-002
When the horizontal dimension of the tray exceeds "315 mm", mount a
magnet attachment to the tray magnet.
Magnet Attachment
Fig. A14 Tray Magnet with Magnet Attachment
3.6 Tray Magnets
