Tape Splice Tool for SMD Tape Connections Accessories for the Accessories

104 User Manual SIPLACE S-Feeder

6.1.6.4 Examples of Correct Splice Connections

6.1.7 Accessories for the Accessories

For optimum tape splicing, you can order the following items:

▪

SIPLACE Operator Kit

Item No. 00349303-xx

The Operator Kit contains 1 leather case, 1 pair SMD tweezers, 1 small slotted screwdriver, 1 small

Phillips screwdriver, 1 pair scissors and 1 brush.

▪

Shuck holder for tape connector

Item No. 00362492-xx

▪ Holder for tape splice tool, Item No. 00362493-xx

▪

Splice trolly

, Item No. 003066234-xx

The documentation for correct splicing of tapes is also available as a poster or spiral bound job guide:

▪Job Poster "

Splicing tapes

", Item No. 00192460-xx

▪ Job Guide "

Feeders

", Item No. 00191256-xx

Legend:

1 8 mm paper tape 5 24 mm blister tape

2 8 mm blister tape 6 32 mm blister tape

3 12 mm blister tape 7 44 mm blister tape

4 16 mm blister tape 8 56 mm blister tape
