Cable trees
Page 21 / 25 19.11.2021
Cable trees
Page 22 / 25 19.11.2021
Pos. Item no. Description Part marking
00305809-02 CABLE: MAIN ERROR DISPLAY
103 00321474-02 CABLE POWER SUPPLY
109 00300383-02 CABLE: CONTROL UNIT - I/O UNIT
110 00300384-03 CABLE: TERMINAL BOARD -
INTERFACE
111 00313403-01 CABLE: INTERFACE - TAPE CUTTER
112 00318149-01 CABLE: TERMINAL BOARD -
INTERFACE
124 00328858-01 CABLE : TERMINAL BOARD - OVERV.
PROTEC.
125 00328857-01 CABLE : TERMINAL BOARD -
CIRCUIT BREAKER
133 00300407-03 CABLE: RLCD MEASURING UNIT
134 00300417-03 CABLE RLCD-MEASURING UNIT
135 00320800-03 CABLE: I/O INTERWIRING BOARD
136 00320802-04 CABLE: I/O INTERWIRING BOARD
137 00317222-03 CABLE: TRACK (X-AXIS)
138 00317505-03 CABLE: TRACK X-AXIS
139 00320801-03 CABLE: I/O INTERWIRING BOARD
140 00320803-03 CABLE: I/O INTERWIRING BOARD
141 00317228-02 CABLE: MOTOR/SPEEDO DP1-AXIS
W3
142 00317511-02 CABLE: MOTOR/SPEEDO DP1-AXIS
143 00317501-02 CABLE: MOTOR/SPEEDO DP2-AXIS
144 00317513-02 CABLE: MOTOR/SPEEDO DP2-AXIS
145 00317224-02 CABLE: MOTOR/TACHO DR-AXIS
SP/IC1-HEAD
146 00317507-02 CABLE: MOTOR/SPEED DR-AXIS
SP/IC1-HEAD
147 00317226-02 CABLE: MOTOR/SPEEDO Z-AXIS
SP/IC1-HEAD
148 00317509-02 CABLE: MOTOR/SPEEDO Z-AXIS
SP/IC1-HEAD
149 00317220-02 CABLE: TRACK (Y-AXIS)
150 00317503-02 CABLE: MOTOR/TACHO Y-AXIS
151 00301487-06 CABLE: CONTROL UNIT-
CONVERSION BOARD
152 00301488-04 CABLE: CONTROL UNIT -
CONVERSION BOARD
Cable trees
Page 23 / 25 19.11.2021
Pos. Item no. Description Part marking
153 00300405-02 CABLE: MOTOR STEP 1/2 AND
MOTORS
154 00300415-03 CABLE MOTOR SCREWDRIVER 1/2
AND MOTORS
155 00317227-02 CABLE: MOTOR/TACHO DP1-AXIS
W1/W2
156 00317510-02 CABLE: MOTOR/TACHO DP2-AXIS
157 00317266-02 CABLE: MOTOR/TACHO DP2-AXIS
W1/W2
158 00317512-02 CABLE: MOTOR/TACHO DP2-AXIS
159 00317223-02 CABLE: MOTOR/TACHO DR-AXIS
SP/IC1-HEAD
160 00317506-02 CABLE: MOTOR/TACHO DR-AXIS
SP/IC1-HEAD
161 00317225-02 CABLE: MOTOR/TACHO Z-AXIS
SP/IC1-HEAD
162 00317508-02 CABLE: MOTOR/TACHO Z-AXIS
SP/IC1-HEAD
163 00300406-02 CABLE: CRASH-BERO'S CABLE:
CRASH-BERO'S
164 00300416-02 CABLE: CRASH-BEROS
165 00317221-03 CABLE: MOTOR/TACHO X-AXIS
166 00317504-03 CABLE: MOTOR/TACHO X-AXIS
42 00326030-02 CABLE MOTOR OUTPUT BELT 1
235 00326032-01 CABLE MOTOR INPUT BELT 1
250 00326031-02 CABLE: MOTOR CENTER BELT1 SPARE PART
325 00326026-02 CABLE VALVE STOPPER 1 SPARE PART
434 00326061-01 CABLE STEPPING M. LIFTING TABLE
1 - CON
435 00326063-01 CABLE POWER SUPPLY - STEPPING
MOTOR CON
436 00326064-01 CABLE SIGNALS LIFTING T. 1 -
CONV. BOARD
437 00331297-01 CABLE: I/O CONVEYOR BELTS
30-POLE
438 00326067-01 CABLE POWER SUPPLY - HALF
BRIDGE
452 00326070-01 CABLE: POWER UNIT CONVERSION
PCB
Spare Part
453 00326068-01 CABLE:OUTPUTCLAMP FIELD- Spare Part
