Station Software Version 712.0 (R18-2) / Installation Manual 11/2018 Edition
18
4.2 Hardware Components of SIPLACE Series X, X S, SX, DX, CA and
TX
4.2.1 Station Computer
Name SIMATIC BoxPC 627B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 2 GB
Harddisk HDD
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 4-3: Station computer hardware SIPLACE X-, SX- and DX-series
Name SIMATIC BoxPC 827B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 2 GB
Harddisk HDD
Internal DVD drive Yes
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 4-4: Station computer hardware SIPLACE X-, SX- and DX-series
Name SIMATIC BoxPC 627C
CPU / clock frequency Intel® Celeron® P4505 / 1.87 GHz
RAM 2 GB
Harddisk HDD
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 4-5: Station computer hardware SIPLACE X-, X S-, SX-, DX-series
Station Software Version 712.0 (R18-2) / Installation Manual 11/2018 Edition
19
Name SIMATIC BoxPC 827C
CPU / clock frequency Intel® Core
(TM)
i3 / 2.13 GHz
RAM 2 GB
Harddisk HDD
Serial interfaces 1
USB interfaces Yes
Network 2x 100 MBit
Table 4-6: Station computer hardware SIPLACE X-, X S-, SX-, DX- and CA-series
Name SIMATIC BoxPC 627D/827D
CPU / clock frequency Intel® Core(TM) i3 / 2,40 GHz
Exchange PC for 60x:
Intel® Celeron® G1820TE / 2,20 GHz
RAM 4 GB
Harddisk SSD
Serial interfaces 1
USB interfaces Yes
Network 2x 1000 MBit
Table 4-7: Station computer hardware SIPLACE X- and CA-series
Name iBase ABP 402-A
CPU / clock frequency Intel® Celeron® CPU 1020E / 2,2 GHz
RAM 4 GB
Harddisk SSD (SX-series), HDD (E by SIPLACE)
Serial interfaces 2
USB interfaces Yes
Network 2x 1000 MBit
Table 4-8: Station computer hardware SIPLACE SX-series, E by SIPLACE
Name SIMATIC MicroBox 427D
CPU / clock frequency Intel® Core
(TM)
/ 1,6 GHz
RAM 4 GB
Harddisk SSD
Serial interfaces 1
USB interfaces Yes
Network 2x 1000 Mbit
Table 4-9: Station computer hardware SIPLACE X-Series S, TX- and CA-series
Station Software Version 712.0 (R18-2) / Installation Manual 11/2018 Edition
20
4.2.1.1 Station Computer/Coplan Computer with 3D Coplan Sensor
Optionally, the coplanarity module with the 3D coplan sensor (type 37) can be installed in the
SIPLACE X-series, SX1/SX2 (V2) and X-series S placement machines.
Detailed information on the 3D coplanarity module can be found in the corresponding Assembly
Instructions, item numbers [00195344-xx] (for X-series), [00196842-xx] (for SX1/SX2) und
[00197395-xx] (for X-series S).
4.2.1.2 Station Computer/Feeder Computer for SIPLACE BulkFeeder X
Optionally, the SIPLACE BulkFeeder X can be set up and installed at the X-series, X-series S,
X4 S micron and SX1/SX2 (V2) placement machines.
Detailed information on the SIPLACE BulkFeeder X can be found in the SIPLACE BulkFeeder X
Operating Manual, item no. [00198045-xx].
