Station Software Ver sion 712.0 (R18 - 2) / Installation Manual 11/2018 Edition 31 The Insert MID and SerialNumber di alog box is disp layed. Figure 5-11: Inserting Machine Ide ntification Number (MID) and se rial number…
Station Software Version 712.0 (R18-2) / Installation Manual 11/2018 Edition
30
NOTICE
► If you want to change the password for the SIPLACEYats account and an older
station software version is already installed, you must uninstall the old station
software version manually first.
► If problems occur during installation of the SIPLACEYats account after that, you must
delete the account manually and install it again.
► Click the Next button.
The Select machine type dialog box is displayed.
Figure 5-10: Selecting the machine type
► Select the machine type for which the software shall be configured.
This entry field will be empty in the following cases:
– At initial installation.
– If a previous station software version < 710.x has been automatically uninstalled by the setup
wizard before installation.
– If a previous station software version 710.x (or higher) has been manually uninstalled before
installation. In this case, an initial installation will be performed.
► Click the Next button.
Station Software Version 712.0 (R18-2) / Installation Manual 11/2018 Edition
31
The Insert MID and SerialNumber dialog box is displayed.
Figure 5-11: Inserting Machine Identification Number (MID) and serial number
► Enter the 8-digit machine identification number in the MID-Number entry field.
► Enter the serial number in the SerialNumber entry field.
NOTICE
You will find the MID and the serial number on an adhesive label on the side of the
protective covers directly below the label for the number of the relevant location. The
number following the dash after the MID specifies the location and is not entered here
(e.g. 00000001-2 stands for location 2).
► Click the Next button.
Station Software Version 712.0 (R18-2) / Installation Manual 11/2018 Edition
32
The station software is now ready to be installed. The following dialog box is displayed.
Figure 5-12: Checking disk space
Before installing, you can check the available, required and recommended disk space (per drive) to
perform the installation.
NOTICE
For installation and optimal functionality of the machine later on, a free disk space of at
least 5 GB is recommended on the "C:" drive.
► Click the Disk Space button.
The Disk Space Requirements dialog box is displayed.
Figure 5-13: Disk space requirements
► Click the OK button.
