7. LA / LAHD Unit
When looking at the equipment from the rear, this unit is located at the right edge of the base frame.
There are 3 I/F PWB (for L, C, R heads) in the LAHD (E9632721000) mounted on the head of the
KE-760.
There are 2 I/F PWB (for L, R heads) in the LA (E9637725000) mounted on the head of the KE-750.
Furthermore, there is a base PWB assy (E86067250A0) mounted on the left face of this unit.
The feeder unit PWB assy (E86147250A0) and the feeder I/F PWB A assy (E8618721AA0) in the rear
are mounted to a plate at the right of the base frame.
Base PWB ass
y
KE-750: LAHD I/F PWB
KE-760: LA I/F PWB
KE-750: LAHD I/F
PWB
KE-750: LAHD I/F PWB
KE-760: LA I/F PWB
Base frame
Feeder unit PWB ass
y
Feeder I/F PWB ass
y
1-131
8. Conveyor Unit
8-1 Conveyor Unit Structure
Conveyor unit structure is shown in Dia. 17 - 8 - 1.
The CARRY PWB and stepping driver are mounted at the rear above the base frame.
Conveyo
r
Conveyo
r
IN senso
r
IN moto
r
WAIT senso
r
BU senso
r
(Up/Down)
Base frame (top)
(Front)
SLOW senso
r
STOP senso
r
Center moto
r
OUT senso
r
OUT moto
r
(Rear)
HM001320000
5 phase stepping driver
E86177210A0
CARRY PWB
Fig. 17-8-1
