4.21 Others
4.21.1 File Input
Select "4/Others" then "1/File Save" and the setting values are saved in file.
(1) Relevant Data
Data Name File Name
Ver 3.XX & prior Ver 4.00 & after
MS Parameters MSP. TMP MSP. V40
Machine Coordinate Value Data MECHPOS. TMP MECHPOS. V40
Machine Setup Data SETUP. TMP SETUP. V40
Mechanical Control Parameters CTRL. TMP CTRL. V40
Operating Options, Units OPTION. TMP OPTION. V40
Mark Data Base MARKDB. TMP MARKDB. V40
Note: Files from Vers 3.XX & prior (extension TMP) and Vers 4.00 & after (extension V40) are
not structured for mutual compatibility.
(2) Save Address
Machine executed files (extension EXE) are compiled in a storing location.
4.21.2 File Open
Select "4/Others" then "2/File Read" and the file open inquiry dialog will appear.
Yes No
Current data will be lost.
Would you like to stop?
Q004103
Inquir
y
No. Button Selection Process
1 Yes Stops opening of file. Protects current data.
2 NO Opens data from file. Current data is lost.
2-80
(1) Relevant Data
Data Name File Name
Ver 3.XX & prior Ver 4.00 & after
MS Parameters MSP. TMP MSP. V40
Machine Coordinate Value Data MECHPOS. TMP MECHPOS. V40
Machine Setup Data SETUP. TMP SETUP. TMP
Note: Files from Vers 3. & prior (extension TMP) and Vers 4. & after (extension V40) are not
structured for mutual compatibility.
- Ver 3.XX & prior cannot open files from Ver 4.00 & after.
- Ver 4.00 & after cannot open files from Ver 3.XX & prior.
(2) Open Address
Machine executed files (extension EXE) are opened in a storing location.
2-81
4.21.3 EEPROM Clear
Select "4/Others" then "3/EEPROM Clear" and the clear inquiry dialog appears.
Yes No
Current data will be lost.
Would you like to stop?
Q004103
Inquir
y
No. Button Selection Process
1 Yes Stops total clearing of EEPROM domain. Protects currently stored data.
2 No Totally clears EEPROM domain. Currently stored data is lost.
(1) Relevant Data
Totally clears EEPROM domain
– MS Parameters
– Machine Coordinate Data
– Machine Setup Data
– Mechanical Control Parameters
– Operating Options, Units
– Mark Data Base
(2) Specifications for Clear
– Only clears data within the EEPROM
Has no effect on data in RAM.
– In case EEPROM is accidentally cleared, save data when exiting MS parameters.
However, the only types of data that can be saved in EEPROM from MS parameter input are
MS parameters, machine coordinate value data and machine setup data. Nothing else can
be recovered.
– If EEPROM is cleared without saving and power is cut, when restarted, all data from RAM is
set to default.
Default data is not saved in EEPROM. It is obtained when machine is started up.
To save default data in EEPROM, input through MS parameters.
However, the only types of data that can be saved in EEPROM from MS parameter input are
MS parameters, machine coordinate value data and machine setup data. Nothing else can
be saved.
