MODEL TCM-3200J 0102-001 Key No . P AR T No. P AR T NAME Q’ty REMARKS NOTE 105 4-12 1 630 0 70 91 17 SUPPORT 1 759E--01B-046 2 630 070 9124 SUPPORT 1 759E--01B-047 3 630 069 5694 SPRING,FLA T 2 759E--01B-045 4 630 070 99…
MODEL TCM-3200J
0102-001
104
中間ベース部 MIDDLE BASE SECTION
Fig. 4-12 中間ベースカバー Middle Base Cover
See Fig.4-1
See Fig.4-1
Key No.11
Key No.11
26
17
17
18
18
19
19
8
9
10
10
14
14
15
15
11
11
12
12
13
13
14
14
15
15
8
9
10
10
27
28
29
1
5
3
4
2
5
3
4
16
16
7
6
MODEL TCM-3200J
0102-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
105
4-12
1 630 070 9117 SUPPORT 1 759E--01B-046
2 630 070 9124 SUPPORT 1 759E--01B-047
3 630 069 5694 SPRING,FLAT 2 759E--01B-045
4 630 070 9902 MACHINE SCREW 4 759E--01H-018
5 630 000 7749 BOLT,HEX-SCT 2 M5X10
6 630 069 5731 SUPPORT 1 759E--01B-049
7 630 069 5724 SUPPORT 1 759E--01B-048
8 411 141 4107 WASHER V 5X10X1 4 FW5
9 411 141 6705 WASHER SPR 5 4 SW5
10 630 000 7770 BOLT,HEX-SCT 4 M5X20
11 411 141 4008 WASHER V 4X9X0.8 2 FW4
12 411 141 2905 WASHER SPR 4 2 SW4
13 630 000 7626 BOLT,HEX-SCT 2 M4X10
14 630 069 4598 PLUNGER 2 759E--01H-017
15 411 141 0406 NUT HEX 4 2 M4-3
16 630 070 9100 COVER 1 759E--01B-044
17 411 141 4008 WASHER V 4X9X0.8 2 FW4
18 411 141 2905 WASHER SPR 4 2 SW4
19 630 000 7619 BOLT,HEX-SCT 2 M4X8
26 630 070 9391 COVER 1 759E--01B-051
27 411 141 4008 WASHER V 4X9X0.8 2 FW4
28 411 141 2905 WASHER SPR 4 2 SW4
29 630 000 7626 BOLT,HEX-SCT 2 M4X10
MODEL TCM-3200J
0102-001
106
部品供給部 FEEDER CARRIAGE SECTION
Fig. 5-1 リール軸 Feeder Axis
22
21
21
21
22
22
8
7
6
12
11
10
4
3
9
2
1
12
11
10
2
8
7
6
4
3
9
46
45
44
36
35
34
39
38
37
32
32
32
33
33
33
36
35
34
39
39
38
38
37
37
36
36
35
35
34
34
39
39
38
38
37
37
31
31
33
33
31
31
32
32
33
31
41
41
42
43
