P-0227-001 - 第159页
MEMO
MODEL TCM-3200J
0102-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
156
8-1
53 630 031 0399 BEARING,RADIAL 60 759H--01H-001
53 -1 630 089 8101 COVER 2 759H--01B-058
53 -2 630 089 8118 COVER 2 759H--01B-059
53 -3 630 089 7845 COVER 32 759H--01B-060
54 630 091 4047 BELT,ROUND 2 759H--01H-002
55 630 091 4054 BELT,ROUND 2 759H--01H-038
56 630 091 4924 GUIDE(OKU) 1 759H--01B-013
57 630 091 4931 GUIDE(MAE) 1 759H--01B-014
58 411 141 4008 WASHER V 4X9X0.8 12 FW4
59 411 141 2905 WASHER SPR 4 12 SW4
60 630 000 7633 BOLT,HEX-SCT 12 M4X12
66 630 056 2743 PLATE(L) 1 759H--01B-053
67 411 141 4008 WASHER V 4X9X0.8 4 FW4
68 411 141 2905 WASHER SPR 4 2 SW4
69 630 000 7602 BOLT,HEX-SCT 2 M4X6
71 630 056 2736 PLATE 2 759H--01B-054
72 630 000 0252 SENSOR,PHOTO 2 PHS116, PHS117 759H--01H-045
73 630 000 0269 SENSOR,PHOTO(CONNECTOR) 2 759H--01H-046
74 411 119 1909 WASHER V 3X7X0.5 8 FW3 F
75 411 086 4408 WASHER SPR 3 4 SW3 F
76 411 040 7803 SCR PAN 3X12 4 M3X12 PAN
77 411 141 4008 WASHER V 4X9X0.8 4 FW4
78 411 141 2905 WASHER SPR 4 4 SW4
79 630 000 7619 BOLT,HEX-SCT 4 M4X8
91 630 001 0237 WASHER 4 759H--01H-025
92 411 141 3001 WASHER SPR 6 4 SW6
93 630 000 7886 BOLT,HEX-SCT 4 M6X16
96 630 035 6618 MECH PARTS (SET COLLARS) 1 759H--01H-047
MEMO
MODEL TCM-3200J
0102-001
158
R コンベア部 R CONVEYOR SECTION
Fig. 8-2 コンベア駆動部 Conveyor Driver
See Fig.8-1
See Fig.8-1
Key No.2
Key No.2
23
21
21
20
20
17
17
18
19
20
20
21
6
5
4
6-1
6-1
A
A
22
1
13
14
14
15
15
10
11
12
12
13
14
15
15
10
1
2
3
11
12
12
8
7
8
7
9
8
7
8
9
7
6
5
4
6-1
3
2
