MODEL HM-G300 0801-002 MM-1 illust-1 ヘッド部 HEAD SECTION Fig. MM-1 電装ボックス部 Electrical Box Section 53 14 81 81 81 81 82 82 60 59 . 58 . 60 59 . 64 . 60 59 . 64 . 57 56 . 73 . 57 56 . 73 . 57 56 . 73 . 57 56 . 63 . 57 56 . 7…
MODEL HM-G300
0801-002
MM illust-1
Fig. MM
ヘッド部
HEAD SECTION
BLOCK1
BLOCK3
BLOCK4
BLOCK2
BLOCK1
BLOCK2
GXH-3
GXH-3J
注)
イラストはBLOCK1,3に多機能ヘッドを装着した例を示しております。
Notice)The illustration shows the example where the Multi-functional Head is mounted
onto the BLOCK 1.3.
MODEL HM-G300
0801-002
MM-1 illust-1
ヘッド部
HEAD SECTION
Fig. MM-1
電装ボックス部
Electrical Box Section
53
14
81
81
81
81
82
82
60
59
.
58
.
60
59
.
64
.
60
59
.
64
.
57
56
.
73
.
57
56
.
73
.
57
56
.
73
.
57
56
.
63
.
57
56
.
73
.
57
56
.
73
.
57
56
.
73
.
77
76
.
75
.
2
2
8
7
1
3
4
1
1
13
54
9
52
51
5
12
A141
A145
U17
U28
#MR-MD18
#UB28*001
#MR-MD18-FJ
M3X10
SW3
FW3
M3X12
SW3
FW3
M3X12
SW3
FW3
M4X12
M3X6 PAN
+SW+W
M3X18 PAN
+SW+W
M3X18
PAN
+SW+W
M3X6
PAN
+SW+W
M3X6 PAN
+SW+W
M3X6 PAN
+SW+W
M3X6 PAN
+SW+W
M3X6 PAN
+SW+W
M3X6 PAN
+SW+W
SW4
FW4
M5X16
SW5
FW5
M4X8
SW4
FW4
M4X8
SW4
FW4
M4X8
SW4
FW4
M4X8
SW4
FW4
M4X8
SW4
FW4
M4X8
SW4
FW4
M4X8
SW4
FW4
81
10
14
81
M3X6 PAN
+SW+W
MODEL HM-G300
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
MM-1 list-1
MM-1
1 6301625447 PLATE 1 867MM-100-301 211DD587
2 6301370767 PLATE 2 867MM-100-302 211DA592
3 6301370774 PLATE 1 867MM-100-303 211DA593
4 6301370781 COVER 1 867MM-100-304 211A9810
5 6301672175 BOX 1 867MM-100-305 211B1417
7 6301554778 BRACKET 1 867MM-100-307 211FC159
8 6301554785 BRACKET 1 867MM-100-308 211FC160
9 6301599038 STAY 1 867MM-100-309 211J1534
10 6301672403 STAY 1 867MM-100-310 211J1587
11 6301348001 BRACKET 3 867MM-100-311 211F9476
12 6301599069 COVER 1 867MM-100-312 211AC355
13 6301370798 COVER 1 867MM-100-313 211A9811
14 6301553658 BRACKET 2 867MM-100-314 211FC147
51 6301242088 UNIT,DRIVER 1 A141 867MM-100-051 4U240441
52 6301317137 UNIT,DRIVER 1 A145 867MM-100-052 4U240449
53 6301242460 P.C.B,MOUNT 1 U17 867MM-100-053 4B111462
54 6301314556 P.C.B,MOUNT 1 U28 867MM-100-054 4B111502
56 4111412905 WASHER SPR 4 24 867MM-100-706 221H0284
57 4111414008 WASHER V 4X9X0.8 24 867MM-100-707 221H0315
58 6300007527 BOLT,HEX-SCT 4 M3X10 867MM-100-708 221A0007
59 4111412806 WASHER SPR 3 10 867MM-100-709 221H0281
60 4111413902 WASHER V 3X7X0.5 10 867MM-100-710 221H0312
63 6300007633 BOLT,HEX-SCT 4 M4X12 867MM-100-713 221A0018
64 6300007534 BOLT,HEX-SCT 6 M3X12 867MM-100-714 221A0008
73 6300007619 BOLT,HEX-SCT 20 M4X8 867MM-100-723 221A0016
75 6300007763 BOLT,HEX-SCT 4 M5X16 867MM-100-725 221A0031
76 4111416705 WASHER SPR 5 4 867MM-100-726 221H0287
77 4111414107 WASHER V 5X10X1 4 867MM-100-727 221H0318
81 6301274546 SCR PAN+SW+W 3X6 27 867MM-100-731 221D0262
82 6301517230 SET SCREW 8 SCR PAN+SW+FW M3X18
867MM-100-732 221D0188
