3-4 Parts Location 5OM-1751 1305-002 Power Breaker Q200 Symbol Name Remarks Q200 Main Breake
3-3
Parts Location
5OM-1751
1305-002
Front
CPU1
LED Light Control PCB
CPU2
XY Motor Amplifier Unit
Front
ATX
Power
3-4
Parts Location
5OM-1751
1305-002
Power Breaker
Q200
Symbol Name Remarks
Q200 Main Breake
3-5
Parts Location
5OM-1751
1305-002
Noise Filter
Z1
Z2
Symbol Name Remarks
Z1 FILTER-NOISE 1
Z2 FILTER-NOISE 2
